16
Chapter 3 Product Description
4 - Certification
Maxphotonics certifies that this equipment has been thoroughly tested and
inspected and meets published specications prior to shipping. Upon receiving
your equipment, check whether the packaging and accessories have been
damaged in transit. If damage is apparent, please contact Maxphotonics
immediately.
5- Front Panel Description
ITEMS FUNCTION DESCRIPTION
(OFF ON) Key Switch Power switch of laser
(EMERGENCY STOP)
Emergency Stop Switch
Emergency stop
(Start) Start Switch Start laser (on-off signal of hardware)
ALARM Abnormal situation light of laser
ACTIVE Normal situation light of laser
POWER Power light of laser
2 Gain media of the laser F means Fiber Laser
3 Laser Module S means Single Module
4 Laser state C means Continue Wave
5 Maximum output power
XXXX W means the maximum output power of
the laser
6 Additional message Can be null
EMERGENCY STOP
To Next Page
