35
After Sales Support
UK/N.IRELAND HELPLINE N
O
:
REP.IRELAND HELPLINE N
O
:
WEBSITE:
EMAIL:
01270 508538
1800 995 036
www.quesh.co.uk
enquiries@quesh.co.uk
Assembling Mounts
Waterproof Housing
Lowerthereardoorofthewaterproofhousingandinsertthe
camera.Closeandhookthecatchovertherearlipofthedoor.
Snapthecatchintopositionbypushingforwardoverthehousing
to ensure a waterproof seal.
Camera Frame
Screw the camera frame mount to the brass screw mounts on the
cameraframe.Turnthelockingscrewtosecuretheplacement.
Raisetheclipenoughtoslidethecameraintoposition.Pushthe
cameraintotheframeandcheckthattheclipisoverthefrontedge
to keep the camera in the frame.
Alternativelyyoucanusethepersonalcliptomountthecamera.
Slide the personal clip on the back of the camera frame. Use the
crocodilecliptomountthecameraonclothing,strapsorbags.
