Chapter 2: Locations
Exterior Views
Hull Views
STERN EYES
BOARDING
LADDER
TRIM TAB
MACERATOR DISCHARGE
(IF EQUIPPED)
BILGE DRAIN
PLUG
TRANSOM VIEW
PORT HULL SIDE VIEW
BOW EYE
GALLEY SINK DRAIN
PORTLIGHT
DECK
DRAIN
WATER HEATER
OVERFLOW
WATER TANK
VENT
GRAY WATER
VENT (IF EQUIPPED)
BOW EYE
ANCHOR
LOCKER
DRAIN
PORTLIGHTS
HEAD SINK
MID BILGE DRAIN
DRAIN
SUMP BOX DRAIN
ENTRY SLIDER
DRAIN
DECK
DRAIN
AFT BILGE
DRAIN
HOLDING TANK VENT
PORTLIGHT
AIR CONDITIONER
STARBOARD HULLSIDE VIEW
DRAINS (IF EQUIPPED)
FUEL TANK VENT
TRIM TAB
