CHAPTER 7: DECK EQUIPMENT 33
Bimini Top
1. Slide the swivel ends of the main bow (A) over the windshield frame and insert the securing pins.
2. Unfold the bimini top (B).
3. Slide the swivel ends of the forward legs (C) over the windshield frame and insert the securing pins.
4. Slide the eye ends of the aft legs (D) into the forward deck hinges (E) and insert the securing pins.
Camper Canvas
1. Slide the eye ends of the main bow (F) into the mid deck hinges (G) and insert the securing pins.
2. Unfold the camper canvas (H) and zip it to the bimini top (B).
3. Slide the eye ends of the aft legs (I) into the aft deck hinges (J) and insert the securing pins.
Windshield Curtain
1. Zip the windshield curtain (L) to the bimini top (B) and snap to the windshield frame.
Side Curtains
1. Zip the forward side curtains (M) to the bimini top (B) and snap to the deck of the boat.
2. Zip the aft side curtains (N) to the camper top (H) and snap to the deck of the boat.
Windshield Wiper
When necessary, replace the wiper blade with an 18" blade refill.
Cleats and Tow Eyes
Carefully read the section on towing in the Cruiser & Yacht Owner’s Manual before towing anything behind the boat
or having the boat towed by another vessel.
PERSONAL INJURY and /or PRODUCT or PROPERTY DAMAGE HAZARD!
• NEVER lift the boat using the bow and stern eyes or the cleats.
WARNING!
!
