19
Chapter 6: Plumbing
Bilge Pumps
• Your boat is equipped with
two automatic impeller-type
bilge pumps which are used to
pump water out of the bilge.
• The bilge pumps are con-
trolled by automatic bilge
pump float switches (autof-
loat switches) and/or switches
at the helm.
• The bilge pumps are wired
directly to the battery so they
will normally function even
when the boat is completely
shut down and left unattended.
NOTICE
Discharge of oil, oil waste or fuel into navigable waters is prohibited by law. Violators are sub-
ject to legal action by the local authorities.
AFT BILGE PUMP
FORWARD BILGE PUMP
AFT BILGE PUMP
& FLOAT SWITCH
THRU-HULL
THRU-HULL
FORWARD
BILGE PUMP &
FLOAT SWITCH
