Maxxus CX 5.1 User Manual

Parts List
31
Part no. Description Qty Part no. Description Qty
A01 Main frame 1 B39 Sheet metal screw, M4 6
A02 Upright support 1 B40 Sheet metal screw, M5 32
A03 Dual action tube, left 1 B42 Bushing 2
A04 Dual action tube, right 1 B43 Zinc plate 2
A05 Foot pedal tube, left 1 B44 Hex head screw, M8 4
A06 Foot pedal tube, right 1 C01 Main cover, right 1
A07 Foot pedal, left 1 C02 Main cover, left 1
A08 Foot pedal, right 1 C03 Disc cover 1
A09 Stabilizer tube 1 C04 End cap for stabilizer bar 4
A10 Shaft pulley 1 C05 Height adjuster 4
A11 Crank assembly 2 C06 Transportation wheel 2
A12 Tube, guide rails 1 C07 Upright joint cover, left 1
A13 Dual action handle bar, left 1 C08 Upright joint cover, right 1
A14 Dual action handle bar, right 1 C09 End cap for foot pedal tube 6
A15 Tension wheel arm, welded 1 C10 Belt 1
A16 Hand pulse handle bar 1 C11 Nut cap 8
B01 Hex bolt, 1/4" 2 C12 Foot pedal 2
B02 Washer, 1/4" 4 C13 Foam grip 2
B03 Lock nut, 1/4" 2 C14 Plug for foot pedal 8
B04 Nut, 3/8" 2 C15 Foam grip 2
B05 Screw, M5 2 C16 Dome end cap 2
B06 C-clip 1 C17 Nut cap 4
B07 Wave washer, M21 2 C18 Round end cap, Ø1-1/4" 2
B08 Washer, M20 1 C19 Pulley 1
B09 Bushing spacer 10 C20 Roller 2
B10 Hex head screw, M10 1 C21 Height Adjuster 2
B11 Allen key screw, M10 1 C22 Washer 4
B12 Allen key screw, M12 2 C23 Spacer 6
B13 Allen key screw, M8 8 C24 Bearing bushing 10
B14 Washer, Ø1/2" 2 C25 Bearing housing 10
B15 Lock nut, M12 2 C26 Bushing 6
B16 Screw, M8 2 C27 Water bottle holder 1
B17 Screw for computer 4 C28 Square end cap 2
B20 Bolt, M5 2 C29 End cap 2
B21 Hex head screw, 3/8" 4 C30 End cap 1
B22 Dome nut, 3/8" 2 D01 Hand pulse sensor 1
B23 Allen key screw, M6 8 D02 Computer 1
B24 Allen key screw, M8 2 D03 Magnetic flywheel 1
B25 Black nut, M8 1 D04 Cable 1
B26 Lock nut, M10 3 D05 Cable 1
B27 C-clip 1 D06 Motor with cable 1
B28 Carriage bolt, M8 4 D07 Sensor cable 1
B29 Lock nut, M8 6 D08 AC adapter 9V, 1.500 mA 1
B30 Curve washer, M8 12 D09 AC plug cable 1
B31 Saft for dual action arm 2 D10 Hand pulse cable 1
B32 Pivot Hex head screw, M8 6 D11 Motor tension cable 1
B33 Washer, Ø5/16" 8 E01 Bearing 6004 2
B34 Hex head screw, M10 2 E02 Bearing 6003 10
B35 Allen key screw, M8 4 E03 Bearing 6001 4
B36 Sheet metal screw, M3 2 E04 Bearing 6203 2
B37 Sheet metal screw, 3/16" 1 F01 Aluminum guide rail 2
B38 Sheet metal screw, M3 2
