Carefully unpack all parts of the delivery. Two people are required because some parts of your exercise machine
are bulky and heavy. Before starting, check the completeness of the fastening material (screws, nuts, etc.) and
the components.
Damage or defects resulting from assembly mistakes are not covered by the warranty or guarantee under any
circumstances. Therefore, please read the instructions carefully before assembly, follow the sequence of
assembly steps exactly, and adhere to the instructions provided for each individual assembly step.
The installation of the training device must be carried out by responsible adults. Since some components may
have sharp edges, it is advisable to wear appropriate work gloves while assembling.
Please assemble your training device in a level, clean area free from any objects that may obstruct the assembly
process. Carry out the assembly with 2 people. Remember, you can only begin exercising once the assembly of
your training device is complete.
Fixing Material & Tools
Assembly
1 (B20)
4 (B32) 5 (B21) 6 (B30)
Hexagon Screw 3/8"
x 64 mm 2 pcs.
Washer 5/16"
x 20 x 2.0 4 pcs.
Hexagon screw M8
x 16 mm 4 pcs.
Washer 3/8"
x 20 x 2.0 4 pcs.
Curved Washer M8
x 20 x 1.5 10 pcs.
7 (B28) 8 (B40) 9 (B44) 12 (B13) 13 (B22)
Carriage Bolt M8
x 50 mm 4 pcs.
Parker Screw M5
x 16 mm 2 pcs.
Hexagon Screw M8
x 20 mm 4 pcs.
Allen Screw M8
x 18 mm 6 pcs.
Cap nut 3/8"
6 pcs.
14 (B29) 10 11
Lock nut M8
4 pcs.
Screwdriver &
Wrench 1 pc.
Allen key M5
1 pc.
5
To Next Page
