Assembly - Multipress
Step 13
16
17
15
59
59
17
16
Spare parts of installation step
No. Product name Qty. No. Product name Qty.
15 Chest clamping assembly-R 1 17
Chest clamping aluminum
decorated fixed cover
2
16
Chest clamping assembly
-L
1 59
Inner hexagon pan head
screw：M10*20
2
