15
Assembly - Multipress
Step 12
14
50
63
50
63
Spare parts of installation step
No. Product name Qty. No. Product name Qty.
14 Chest clamping assembly 1
50
External hexagon screw：M10*20
2
63
Flat washer ：φ10
2
