Assembly - Multipress
Step 11
14
As shown in the picture, install
No.18 and lock it with screw by
using the 4# inner hexagon
wrench .
(This screw is pre-locked on
No. 18 ).
Note:
1: Two people are required to install this step .Please hole two ends of the hand guide rod at the same time in the
direction of the above picture and install No.17 that installed in step 11 to main frame.
2.As shown in the picture in the circle, do not allow accessories to escape.
