PAGE 8
FOR SERVICE TECHNICIAN’S USE ONLY
DO NOT REMOVE OR DESTROY
TROUBLESHOOTING GUIDE
PROBLEMPOSSIBLE CAUSE CHECKS & TESTS
No power to dryer. Check power at outlet, check circuit breaker,
fuses, or junction box connections.
Connection problem between AC plug and dryer.See Test #2: Supply Connections, page 10.
Connection problem between CCU and UI.Check connections and continuity between
CCU and UI.
Power supplies not present at machine electronics. See Te st #1: CCU Power Check, page 9.
User Interface problem. See Test #6: Buttons & Indicators, page 19.
Door not fully closed or striking the door latch.Be sure the door is completely closed,
then press and hold the “start” button.
Door Switch problem. See Te st #7: Door Switch, page 20.
Drive Belt / Belt Switch problem. See Te st #3: Motor Circuit, page 12.
Thermal Fuse / Motor problem. See Te st #3: Motor Circuit, page 12.
User Interface problem. See Test #6: Buttons & Indicators, page 19.
CCU problem. See Te st #1: CCU Power Check, page 9.
Poor airflow.Check lint screen and exhaust vent. Clean
if necessary.
Check the “pause/cancel” button. Perform UI Component Te st under
Component Activation.
Moisture Sensor problem. See Te st #5: Moisture Sensor, page 18.
Thermistor problem. See Te st #4a: Thermistors, page 15.
User Interface problem. See Test #6: Buttons & Indicators, page 19.
CCU problem. See Te st #1: CCU Power Check, page 9.
User selects invalid option. Refer customer to “Use and Care Guide”.
User Interface problem. See Test #6: Buttons & Indicators, page 19.
Drive Belt / Belt Switch problem. See Te st #3: Motor Circuit, page 12.
Thermal Fuse (electric only). See Te st #4b: Thermal Fuse, page 17.
Door switch problem. See Te st #7: Door Switch, page 20.
Motor problem. See Te st #3: Motor Circuit, page 12.
CCU problem. See Te st #1: CCU Power Check, page 9.
Check installation. Verify proper dryer installation.
Check for L1 and L2. Perform CCU L1 and L2 tests under Install
Diagnostics.
Heater system malfunction or open heater coil. See Te st #4: Heat System, page 13.
CCU problem. See Te st #1: CCU Power Check, page 9.
Heater coil shorted. See Te st #4: Heat System, page 13.
Heater relay shorted. See Te st #4: Heat System, page 13.
Heater system problem. See Te st #4: Heat System, page 13.
Dryness setting for auto cycles.Increase drying times for one or more
Lint screen full. Clean if necessary. Refer customer
to “Use and Care Guide”.
Heater vent clogged. Clean if necessary. Refer customer
to “Use and Care Guide”.
Moisture Sensor problem. See Te st #5: Moisture Sensor, page 18.
Adjust Customer Focused Dryness Level. See Te st #5a: Adj. Cust. Focused
Dryness Check, page 19.
Steam cycle not selected. Refer customer to “Use and Care Guide”.
No water to valve. Verify water supply is turned on.
No water from valve. See Te st #9: Water Valve, page 20.
WATER VALVE NOT DISPENSING
(
Water valve is activated intermittently
during the steam cycle.)
WILL NOT HEAT
HEATS IN AIR CYCLE
SHUTS OFF BEFORE CLOTHES
ARE DRY
DRUM WILL NOT SPIN
CONSOLE WON’T ACCEPT
SELECTIONS
WILL NOT POWER UP
- No operation
- No keypad response
- No LED's or display
WILL NOT START CYCLE
(No response when “start” button
is pressed.)
WILL NOT SHUT OFF
WHEN EXPECTED
auto cycles.
