Supreme M3 Disassembly Instructions
6. Dismantling the Drive System
Step 6.1
Remove the
pulley
together
with the
track.
Step 6.2
Remove the
guide
wheels.
Step 6.3
Remove the
tracks.
Note:
The pulley and
guide wheels
are on one
side only, the
drive motor
side
Note:
The M3 has a
shorter track on
the side without
the pulley and
guide wheels.
6.1
