7. Assembling the Floating Cable
Step 7.1
Insert the floating
cable to the
motor unit.
Step 7.2
Connect the
cable's retrofit to
motor unit (mind
the slot shape)
and press it
firmly.
Step 7.3
Press the seal
firmly to the
terminal.
Step 7.4
Tighten the nut
properly by hand.
4.
4
Note:
There is only
one way for
the connector
to connect to
the motor
unit terminal.
