Supreme M4 Assembly Instructions
Page 2 of 18
1. Assembling the Motor Unit’s Parts
Step 1.1
Secure the
impeller with a
4X25 screw.
Step 1.2
Secure the
impeller protector
cylinder with 4
KA50X12 screws.
