Vent Operation
qAdjusting the Vents
Directing airflo w
To adjust the direction of airflow, move
the adjustment knob.
NOTE
When using the air conditioner under humid
ambient temperature conditions, the system
may blow fog from the vents. This is not a sign
of trouble but a result of humid air being
suddenly cooled.
Side Vents
Open
Knob
Dial
Close
Center Vents
Knob
Interior Features
Climate Control System
5-3
