Spare Tire and Tool Storage
Spare tire and tools are stored in the locations illustrated in the diagram.
Except Mexico
Spare tire
Spare tire hold-down bolt
Tire hold-down bolt
Jack
Lug wrench
Jack lever
Tiedown eyelet (Short type)
Tiedown eyelet (Long type)
Some models.
If Trouble Arises
Flat Tire
7-3
