(With Front Passenger Occupant Classification System)
In a roll-over:
In response to a vehicle roll-over, both curtain air bags inflate.
Both curtain air bags will deploy after
the roll-over accident is detected.
(With Front Passenger Occupant Classification System)
In an angled coll ision:
During a collision, the drive r and front passenger's air bags will deploy. Depending on the
nature of the impact, the curtain air bag may deploy.
qWarning Light/Beep
A system malfunction or operation conditions are indicated by a warning.
Refer to Warning/Indicator Lights on page 4-22.
Refer to Air Bag/Front Seat Belt Pretensioner System Warning Beep on page 7-33.
2-52
Essential Safety Equipment
SRS Air Bags
