5. Turn the socket and bulb assembly to
remove it. Carefully remove the bulb
from its socket in the reflector by
gently pulling it straight backward out
of the socket.
6. Install the new bulb in the reverse order
of the removal procedure.
Front direction indicator lights,
Position lights (With halogen
headlights)
1. Make sure the ignition is switched off,
and the headlight switch is off.
2. If you are changing the right bulb, start
the engine, turn the steering wheel all
the way to the right, and turn off
engine. If you are changing the left
bulb, turn the steering wheel to the left.
3. Pull the centre of each plastic retainer
and remove the retainers.
Installation
Removal
4. Turn the screw anticlockwise and
remove it, and then partially peel back
the mudguard.
5. Turn the socket and bulb assembly
anticlockwise and remove it.
6. Disconnect the bulb from the socket.
6-54
Maintenance and Care
Owner Maintenance
