Front direction indicator lights
Position lights
7. Install the new bulb in the reverse order
of the removal procedure.
Front fog lights (With LED headlights)
The LED bulb cannot be replaced as a
single unit because it is an integrated unit.
The LED bulb has to be replaced with the
unit. We recommend an Authorised
Mazda Repairer when the replacement is
necessary.
Front fog lights (With halogen
headlights)
í
1. Make sure the ignition is switched off,
and the headlight switch is off.
2. If you are changing the right bulb, start
the engine, turn the steering wheel all
the way to the right, and turn off
engine. If you are changing the left
bulb, turn the steering wheel to the left.
3. Pull the centre of each plastic retainer
and remove the retainers.
Installation
Removal
4. Turn the screw anticlockwise and
remove it, and then partially peel back
the mudguard.
Maintenance and Care
Owner Maintenance
6-55
í
Some models.
