BODY STRUCTURE [PLASTIC BODY PARTS]
09-80E–1
09-80E
09-80E BODY STRUCTURE [PLASTIC BODY PARTS]
PLASTIC PARTS HEAT RESISTING
TEMPERATURE
[PLASTIC BODY PARTS] . . . . . . . . . . . 09-80E–1
REPAIRABLE RANGE OF
POLYPROPYLENE BUMPERS
[PLASTIC BODY PARTS] . . . . . . . . . . . 09-80E–2
Repairable Bumpers . . . . . . . . . . . . . . .09-80E–2
POLYPROPYLENE BUMPER
REPAIR[PLASTIC BODY PARTS] . . . . .09-80E–3
PROCEDURE[PLASTIC BODY PARTS] .09-80E–4
End of Toc
BM: PLASTIC BODY PARTS
PLASTIC PARTS HEAT RESISTING TEMPERATURE[PLASTIC BODY PARTS]
id09801 1740200
Note
• The application of temperatures higher than heat resisting temperatures may result in part deformation.
End Of Sie
BM: BUMPER
Part Name Code Material Name
Heat resisting
Temperature(°C {°F})
WINDSHIELD MOULDING PVC POLYVINYLCHLORIDE 95 {203}
COWL GRILLE PP POLYPROPYLENE 95 {203}
FRONT COMBINATION
LIGHT
LENS PC POLYCARBONATE 130 {266}
HOUSING PP POLYPROPYLENE 90 {194}
RADIATOR GRILLE PP POLYPROPYLENE 95 {203}
FRONT BUMPER PP POLYPROPYLENE 100 {212}
OUTSIDE MIRROR
PANEL AAS AAS 100 {212}
VISOR AAS AAS 100 {212}
SIDE STEP MOLDING PP POLYPROPYLENE 75 {167}
SIDE GARNISH AES AES 90 {194}
REAR COMBINATION
LIGHT
LENS PMMA ACRYLIC 80 {176}
HOUSING AAS AAS 70 {158}
REAR BUMPER PP POLYPROPYLENE 100 {212}
ROOF MOULDING PVC POLYVINYLCHLORIDE 95 {203}
REFLECTOR
LENS PC POLYCARBONATE 80 {176}
HOUSING PC POLYCARBONATE 80 {176}
OUTER HANDLE
COLOR
S
LEVER PC-PBT POLYCARBONATE-PBT 138 {248}
BASE PC-PET POLYCARBONATE-PET 140 {252}
EXCEP
T
COLOR
S
LEVER PC-ABS POLYCARBONATE-ABS 125 {225}
BASE PC-ABS POLYCARBONATE-ABS 125 {225}
HIGH-MOUNT BRAKE
LIGHT
LENS PMMA ACRYLIC 100 {212}
HOUSING ABS ABS 94 {201}
SHROUD PANEL PP POLYPROPYLENE 100 {212}
REAR SPOILER ABS ABS 90 {194}
3419-1U-06C(09-80E).fm 1 ページ ２００６年３月２２日 水曜日 午後６時２８分
