BODY STRUCTURE [PLASTIC BODY PARTS]
09-80E–2
REPAIRABLE RANGE OF POLYPROPYLENE BUMPERS[PLASTIC BODY PARTS]
id09801 1600100
The three types of damaged bumpers shown below are considered repairable. Although a bumper which has been
damaged greater than this could also be repaired, it should be replaced with a new one because such repair would
detract from the looks and quality of the bumper. In addition, such repair is not considered reasonable in terms of
work time.
Repairable Bumpers
1. A bumper with a hole less than 50 mm {1.97 in} in
diameter.
2. A bumper with a crack less than 100 mm {3.94 in}
in length.
3. A bumper with a crack less than 100 mm {3.94 in}
in length that is less than half of the width of the
bumper.
End Of Sie
am8rrb00000046
am8rrb00000047
LESS THAN HALF OF (A)
(A)
am8rrb00000048
