Page 105 of 226

Version: 3.3.5 – DR05 – 23.03.2017

Firmware Version 4.x 15.4.1

Because there is no Samba included since firmware V 4.x you can only access the USB device

via SFTP.

Under USB-Devices you can see if a USB-Device is plugged in or not.

Label

Description

Active

Check this box if you like the mbNET to mount the USB device.

SFTP-User

Please enter a valid SFTP-User

SFTP-Password

Please enter the password for the SFTP-User.

SFTP-Password

Confirmation

Please confirm the password which you entered.
