MB Connect Line mbNET MDH816 User Manual

Page 175 of 226
Version: 3.3.5 – DR05 – 23.03.2017
Server – no authentication or static key
19.3.2.1
Tab
Label
Description
Network Settings
Local IP address
Enter the IP address of the local VPN tunnel end
point here, e.g. 10.1.0.1
Peer IP address
Enter the IP address of the peer VPN tunnel end
point here, e.g. 10.1.0.1
Local network
Enter your network address in CIDR notation here
(192.168.0.0/24).
Peer network
Enter the network address of your peer in CIDR no-
tation here (192.168.99.0/24).
With authentication without certificates, only one IP channel (local IP address and peer IP ad-
dress) can be specified per connection entry.
With manual configuration of the VPN client, the setting “Local IP address” and “Peer IP
address” must be reversed accordingly on the client.
