Page 199 of 226

Version: 3.3.5 – DR05 – 23.03.2017

Status - Network 22.3

Label

Description

Physical Con-

nections

Shows the physical connections via which the router is connected to other computers.

Routing Table

Shows all routes used.

Router Listen-

ing Ports

Shows all monitored ports.

Router Con-

nections: Con-

nections to the

Router

Shows all IP addresses with ports, e.g. of computers that are connected to the router.
