10
Common Top Bar for Touch Screen Displays
1. Home:
Pressing will take you back to home screen shown on page 9.
2. Clock:
Displays your current time. Can be set for 12 hr (AM/PM) or 24 hr.
(Refer to settings page 24 for adjustment.)
3. EQ Shortcut:
Press to shortcut to your EQ adjustments.
(Refer to settings page 22 for adjustment.)
4. Day/Night Mode:
Displays your current background mode and if pressed allows
a quick change if Day/Night mode is disabled.
5. Battery Voltage (V):
Displays current battery voltage.
(A warning will be displayed if the voltage gets too low.)
Controls
21 3 4
5
Radio Touch Screen Display
Here we cover the basic functions of your touch screen radio.
1. Seek Tuner Up:
Quick touch to increase radio frequency. Long touch to seek.
2. Tuner Search:
Touch to enable auto seek, the tuner will search for a frequency
with good signal strength. When done, station will play and frequency
will be stored in Preset 1.
1
2
3
4
5
To Next Page
