AUTHORISATION
The authorisation function is enabled when the system is supplied. The RFID cards are
supplied ready-programmed so that their function is enabled.
RFID cards
The four supplied RFID cards are used to
authorise the users at the Wallbox.
All the RFID cards are different colours which,
if the communication module is upgraded, can
also be assigned to a vehicle in the BMW DCS
(BMW Digital Charging Service).
1 RFID master card (white)
2 RFID user card (red, green, blue)
RFID authorisation
The RFID sensor is designed to provide
contactless authorisation of a user for charging at
the Wallbox using RFID cards which comply with
ISO14443 and ISO15693.
1 Status LED
2 RFID status indicator
3 RFID reading area
