McCONNEL MULTIDRIVEM380‐4&M420‐4
107
Axle & Wheel Specification Details
280.8mm diameter hub mounting spigot
10 x 22mm studs at 335 mm PCD-M22 flat nuts
WIDTH OVER AXLE HUB FLANGES 80.7” (2050mm)
Wide Flotation Tyres
In order to avoid tyre contacting the chassis and/or suspension brackets the MINIMUM
width between widest point on tyres is 50" (1270mm). Always adjust axle lock stops to
prevent tyre scuffing on chassis or suspension members. (See set up procedure on page
102).
Maximum Axle Loads (TONNES) subject to suitable tyre equipment.
FRONT
AXLE
7.00
REAR
AXLE
11.00
GVW 16.00
IMPORTANT NOTICE - THE USE OF VERY LARGE WIDTH OR DIAMETER WHEELS
WILL REDUCE AXLE CARRYING CAPACITY
Consult McConnel if in doubt.
See overleaf for the carrying capacities. Various sizes of tyres are quoted for fitment to
the various Multidrive models. RESPECT MUST BE PAID BY USERS TO THE
CARRYING AND SPEED CAPACITY OF THE VARIOUS TYRE OPTIONS AVAILABLE.
FOR ADVICE ON TYRE DATA NOT SHOWN, CONSULT McCONNEL SERVICE
DEPARTMENT OR YOUR LOCAL TYRE DISTRIBUTOR.
