McCONNEL MULTIDRIVEM380‐4&M420‐4
29
Device ID – identifies which ECU is sending the error – e.g. engine, transmission or
steering controller
SPN – The error code number – may allow further to be found information
FMI – A code that may indicate the nature of the error.
Rear steering information area
Please see the appropriate section in the manual for the rear steering operating
instructions
Road mode, headland mode off
Delay mode
Two wheel steer headland mode
Crab mode
Four wheel steer headland mode
Offset LH
Requested mode pop-up
(disappears when mode has
changed)
Offset RH
Offset Auto
Transmission information area
Please see the appropriate section in the manual for the transmission operating
instructions
Automatic mode selected Manual mode selected
Torque converter locked
Torque converter unlocked
Handbrake on
Actual current gear (Neutral shown)
