2
IDENTIFICATION (WHAT IS WHAT?)
Front Handle
Front Hand Guard
Chain
Bar Oil
Fill Cap
Starter Rope
ON/STOP
Switch
Starter Housing
Fuel Mix Fill Cap
Muffler
Bar Sprocket Hole
Bumper
Spike
Bar Guard
Direction
of Chain
Travel
Guide Bar
Chain
Catcher
Clutch
Cover
Choke/Fast
Idle Lever
Throttle
Trigger
Rear
Handle
Cylinder Cover
Throttle
Lock--out
Chain Brake
Bar
Knob
Adjusting
Wheel
IDENTIFICATION OF SYMBOLS
WARNING! This chain
saw can be dangerous! Care-
less or improper use can cause
serious or even fatal injury.
Read and understand the
instruction manual before
using the chain saw.
Always use two
hands when
operating the
chain saw.
WARNING! Contacting the guide bar tip with any object
should be avoided; tip contact may cause the guide bar to
movesuddenly upward andbackward, which may cause se-
rious injury.
Always wear appropriateear
protection, eye protection
and head protection.
Sound
power
level
Sound
pressure
level at 7,5
meters
Chain brake, activated
(right)
Chain brake, not activated
(left)
