1.2 Product overview
11
13
12
6
16
17
15
14
18
10
9
24
19
26
20
22
23
21
25
27
7
8
1
2
3
5
4
The numbers in the figure represent:
1. Body
2. Hatch to display and keypad
3. Stop button
4. Rear wheel
5. Front wheels
6. Charging station
7. Contact plates
8. LED for operation check of the charging
station, boundary wire and guide wire
9. Cutting height adjustment
10. Rating plate (including product identification
code)
11. Display
12. Keypad
13. ON/OFF button
14. Cutting system
15. Blade disc
16. Handle
17. Chassis box with electronics, battery and
motors
18. Battery cover
19. Power supply (the appearance of the power
supply may differ depending on market)
20. Stakes
21. Measurement gauge for help when installing
the boundary wire (the measurement gauge
is broken loose from the box)
22. Couplers for loop wire
23. Screws for securing the charging station
24. Connector for the loop wire
25. Low voltage cable
26. Loop wire for boundary loop and guide wire
27. Operator’s Manual and Quick Guide
