McIntosh C2600 Service Manual

C2600
Ref. No. Description Part No.
DIGITAL PCB 751731 (Cont’d.)
Ref. No. Description Part No.
PARTS LIST (Cont’d.)
65
3
C32 CAP MONO .1uF 50V 20% X7R SMD 061365
C33 CAP MONO .1uF 50V 20% X7R SMD 061365
C34 CAP MONO .1uF 50V 20% X7R SMD 061365
C35 CAP MONO .1uF 50V 20% X7R SMD 061365
C36 CAP MONO .1uF 50V 20% X7R SMD 061365
C39 CAP ELECT 47UF 35V 066446
C40 CAP MONO .1uF 50V 20% X7R SMD 061365
C41 CAP MONO .1uF 50V 20% X7R SMD 061365
C42 CAP .01uF 50V 20% X7R SMD0805 061372
C43 CAP ELECT 47UF 35V 066446
C44 CAP 100pF 200V 5% SMD0805 061390
C45 CAP 100pF 200V 5% SMD0805 061390
C46 CAP .01uF 50V 20% X7R SMD0805 061372
C47 CAP .01uF 50V 20% X7R SMD0805 061372
C48 CAP X7R .022uF 5% 50V SMD0805 061406
C49 CAP .01uF 50V 20% X7R SMD0805 061372
C50 CAP .01uF 50V 20% X7R SMD0805 061372
C51 CAP .01uF 50V 20% X7R SMD0805 061372
C52 CAP NPO 1000pF 100V 5% SMD0805 061391
C53 CAP MONO .1uF 50V 20% X7R SMD 061365
C54 CAP ELECT 10UF 50V 066445
C55 CAP MONO .1uF 50V 20% X7R SMD 061365
C56 CAP .01uF 50V 20% X7R SMD0805 061372
C57 CAP .01uF 50V 20% X7R SMD0805 061372
C58 CAP .01uF 50V 20% X7R SMD0805 061372
C59 CAP ELECT 10UF 50V 066445
C60 CAP MONO .1uF 50V 20% X7R SMD 061365
C61 CAP MONO .1uF 50V 20% X7R SMD 061365
C62 CAP MONO .1uF 50V 20% X7R SMD 061365
C63 CAP MNO 12pF 50V 5% NPOSMD0805 061364
C64 CAP MNO 12pF 50V 5% NPOSMD0805 061364
C65 CAP MONO .1uF 50V 20% X7R SMD 061365
C66 CAP ELECT 47UF 35V 066446
C67 CAP MONO .1uF 50V 20% X7R SMD 061365
C68 CAP MONO .1uF 50V 20% X7R SMD 061365
C69 CAP ELECT 47UF 35V 066446
C70 CAP MONO .1uF 50V 20% X7R SMD 061365
C71 CAP MONO .1uF 50V 20% X7R SMD 061365
C72 CAP MONO .1uF 50V 20% X7R SMD 061365
C73 CAP ELECT 470UF 16V 066508
C74 CAP MONO .1uF 50V 20% X7R SMD 061365
C75 CAP MONO .1uF 50V 20% X7R SMD 061365
C76 CAP MONO .1uF 50V 20% X7R SMD 061365
C77 CAP MONO .1uF 50V 20% X7R SMD 061365
C78 CAP MONO .1uF 50V 20% X7R SMD 061365
C79 CAP MONO .1uF 50V 20% X7R SMD 061365
C80 CAP ELECT 4700UF 16V 20% 066611
C81 CAP MONO .1uF 50V 20% X7R SMD 061365
C82 CAP ELECT 100UF 25V 066573
C83 CAP MONO .1uF 50V 20% X7R SMD 061365
C84 CAP ELECT 470UF 16V 066508
C85 CAP ELECT 100UF 25V 066573
C86 CAP MONO .1uF 50V 20% X7R SMD 061365
C87 CAP NPO 1000pF 100V 5% SMD0805 061391
C88 CAP NPO 1000pF 100V 5% SMD0805 061391
C89 CAP NPO 1000pF 100V 5% SMD0805 061391
C90 CAP NPO 1000pF 100V 5% SMD0805 061391
C91 CAP ELECT 10UF 50V 066445
C92 CAP MPF 0.0022UF 5% 63VDC 064454
C93 CAP MPF 0.0022UF 5% 63VDC 064454
C94 CAP 330pF 100V 5% SMD0805 061377
C95 CAP 330pF 100V 5% SMD0805 061377
C96 CAP ELECT 10UF 50V 066445
C97 CAP 330pF 100V 5% SMD0805 061377
C98 CAP 330pF 100V 5% SMD0805 061377
C99 CAP MONO .1uF 50V 20% X7R SMD 061365
C100 CAP MONO .1uF 50V 20% X7R SMD 061365
C101 CAP ELECT 47UF 35V 066446
C102 CAP ELECT 47UF 35V 066446
C103 CAP MPF 0.0047UF 5% 63VDC 064308
C104 CAP MPF 0.0047UF 5% 63VDC 064308
C105 CAP MONO .1uF 50V 20% X7R SMD 061365
C106 CAP MONO .1uF 50V 20% X7R SMD 061365
D1 DIODE ESD SUPPRESSOR SMD 070198
D2 DIODE ESD SUPPRESSOR SMD 070198
D3 DIODE SMALL SIGNAL 4148 SMD 070199
D4 DIODE SMALL SIGNAL 4148 SMD 070199
DS1 LED BLU/GRN SMD 058201
DS2 LED BLU/GRN SMD 058201
DS3 LED BLU/GRN SMD 058201
DS4 LED BLU/GRN SMD 058201
DS5 LED BLU/GRN SMD 058201
DS6 LED BLU/GRN SMD 058201
DS7 LED BLU/GRN SMD 058201
DS8 LED BLU/GRN SMD 058201
DS9 LED BLU/GRN SMD 058201
DS10 LED BLU/GRN SMD 058201
DS11 LED BLU/GRN SMD 058201
GP1 TERMINAL PC MOUNT 4-40 118115
GP2 TERMINAL PC MOUNT 4-40 118115
J1 CONN USB JACK TYPE B RA 117905
J3 CONN 18 PIN FFC SMD 118003
J4 CONN USB JACK TYPE B VERTICAL 118107
J6 JACK RCA 1X2 BLK/BLK 14MM 117848
J7 CONN 8PIN MINI DIN 117979
J8 CONN 12 PIN FFC SMD 118001
L1 COMMON MODE CHOKE 90 OHM SMD 122454
L2 FERRITE 600 OHM 1 AMP SMD 076026
L3 FERRITE 600 OHM 1 AMP SMD 076026
L4 FERRITE 600 OHM 1 AMP SMD 076026
L5 INDUCTOR 3.3UH 375MA SMD 122428
L6 FERRITE 600 OHM 1 AMP SMD 076026
L7 FERRITE 600 OHM 1 AMP SMD 076026
L8 FERRITE 600 OHM 1 AMP SMD 076026
L9 FERRITE 600 OHM 1 AMP SMD 076026
L10 FERRITE 600 OHM 1 AMP SMD 076026
L11 FERRITE 600 OHM 1 AMP SMD 076026
L12 FERRITE 600 OHM 1 AMP SMD 076026
L13 FERRITE 600 OHM 1 AMP SMD 076026
L14 INDUCTOR 100UH 20% SMD 122440
L15 INDUCTOR 100UH 20% SMD 122440
L16 INDUCTOR 100UH 20% SMD 122440
L17 INDUCTOR 680uH 20% SMD 122441
L18 FERRITE 600 OHM 1 AMP SMD 076026
OPT1 FIBER OPTIC RECEIVER 3-5V 058213
OPT2 FIBER OPTIC RECEIVER 3-5V 058213
OPT3 FIBER OPTIC RECEIVER 3-5V 058213
PCB1 PC DB DIGITAL 130262

McIntosh C2600 Specifications

General

Signal to Noise Ratio	100dB
Phono Stage	Yes
Digital USB Input	1
Digital MCT Input	1
Vacuum Tube	Yes
Type	Tube Preamplifier
Frequency Response	20Hz - 20kHz (+0, -0.5dB)
Phono Inputs	1 Moving Magnet 1 Moving Coil
Outputs	3 Total
Output Impedance	100 ohms
Dimensions	17.5" (44.45cm) x 6" (15.24cm) x 18" (45.72cm)
Headphone Output	1/4" High Drive with Headphone Crossfeed Director (HXD®)
