McIntosh C2600 Service Manual

Ref. No. Description Part No.
PARTS LIST (Cont’d.)
66
DIGITAL PCB 751731 (Cont’d.)
Ref. No. Description Part No.
3
Q1 TRANSISTOR PNP A55 SMD 132334
Q2 TRANSISTOR NPN 20V MUTE 2SC4694 132336
Q3 TRANSISTOR NPN 20V MUTE 2SC4694 132336
R1 RES TF 47.5 1% .125W SMD0805 145128
R2 RES TF 22.1 .5% .1W SMD0805 145113
R3 RES TF 47.5 1% .125W SMD0805 145128
R4 RES SMD0805 47.5K 1/8W 1% 145013
R5 RES TF 22.1 .5% .1W SMD0805 145113
R6 RES TF 22.1 .5% .1W SMD0805 145113
R7 RES TF 10K 1% 0.1W SMD0805 145061
R8 RES TF 10K 1% 0.1W SMD0805 145061
R9 RES TF 10K 1% 0.1W SMD0805 145061
R10 RES TF 10K 1% 0.1W SMD0805 145061
R11 RES TF 10K 1% 0.1W SMD0805 145061
R12 RES TF 10K 1% 0.1W SMD0805 145061
R13 RES TF 10K 1% 0.1W SMD0805 145061
R14 RES TF 10K 1% 0.1W SMD0805 145061
R15 RES TF 10K 1% 0.1W SMD0805 145061
R16 RES SMD0805 100 1/8W 1% 145005
R17 RES SMD0805 100 1/8W 1% 145005
R18 RES TF 10K 1% 0.1W SMD0805 145061
R19 RES SMD0805 270 1/8W 1% 145116
R20 RES TF 10K 1% 0.1W SMD0805 145061
R21 RES TF 10K 1% 0.1W SMD0805 145061
R22 RES SMD0805 33.2K 1/8W 1% 145033
R23 RES TF 10K 1% 0.1W SMD0805 145061
R24 RES TF 10K 1% 0.1W SMD0805 145061
R25 RES TF 10K 1% 0.1W SMD0805 145061
R26 RES TF 10K 1% 0.1W SMD0805 145061
R27 RES TF 10K 1% 0.1W SMD0805 145061
R28 RES TF 10K 1% 0.1W SMD0805 145061
R29 RES SMD0805 33.2K 1/8W 1% 145033
R30 RES SMD0805 33.2K 1/8W 1% 145033
R31 RES SMD0805 33.2K 1/8W 1% 145033
R32 RES SMD0805 33.2K 1/8W 1% 145033
R33 RES TF 10K 1% 0.1W SMD0805 145061
R34 RES SMD0805 1.5K 1/8W 1% 145022
R35 RES TF 22.1 .5% .1W SMD0805 145113
R36 RES TF 22.1 .5% .1W SMD0805 145113
R37 RES TF 10K 1% 0.1W SMD0805 145061
R38 RES SMD0805 1K 1/8W 1% 145007
R39 RES SMD0805 33.2K 1/8W 1% 145033
R40 RES SMD0805 33.2K 1/8W 1% 145033
R41 RES SMD0805 33.2K 1/8W 1% 145033
R42 RES SMD0805 100 1/8W 1% 145005
R43 RES TF 10K 1% 0.1W SMD0805 145061
R44 RES TF 47.5 1% .125W SMD0805 145128
R45 RES TF 10K 1% 0.1W SMD0805 145061
R46 RES SMD0805 100 1/8W 1% 145005
R47 RES SMD0805 221 1/8W 1% 145001
R48 RES SMD0805 221 1/8W 1% 145001
R49 RES TF 47.5 1% .125W SMD0805 145128
R50 RES SMD0805 33.2K 1/8W 1% 145033
R51 RES TF 47.5 1% .125W SMD0805 145128
R52 RES SMD0805 75 1%1/8W 144727
R53 RES SMD0805 1.5K 1/8W 1% 145022
R54 RES SMD0805 1.5K 1/8W 1% 145022
R55 RES SMD0805 1.5K 1/8W 1% 145022
R56 RES SMD0805 475 1/8W 1% 145020
R57 RES SMD0805 475 1/8W 1% 145020
R58 RES SMD0805 475 1/8W 1% 145020
R59 RES SMD0805 75 1%1/8W 144727
R60 RES SMD0805 1.5K 1/8W 1% 145022
R61 RES SMD0805 47.5K 1/8W 1% 145013
R62 RES SMD0805 475 1/8W 1% 145020
R63 RES SMD0805 3.32K 1/8W 1% 145026
R64 RES TF 100K 1% 0.1W SMD0805 145062
R65 RES TF 100K 1% 0.1W SMD0805 145062
R66 RES TF 47.5 1% .125W SMD0805 145128
R67 RES TF 47.5 1% .125W SMD0805 145128
R68 RES TF 47.5 1% .125W SMD0805 145128
R69 RES SMD0805 47.5K 1/8W 1% 145013
R70 RES SMD0805 47.5K 1/8W 1% 145013
R71 RES SMD0805 100 1/8W 1% 145005
R72 RES TF 47.5 1% .125W SMD0805 145128
R73 RES TF 47.5 1% .125W SMD0805 145128
R74 RES SMD0805 33.2K 1/8W 1% 145033
R75 RES SMD0805 47.5K 1/8W 1% 145013
R76 RES SMD0805 100 1/8W 1% 145005
R77 RES SMD0805 3.32K 1/8W 1% 145026
R78 RES TF 47.5 1% .125W SMD0805 145128
R79 RES SMD0805 1K 1/8W 1% 145007
R80 RES TF 1.96k 1% 0.1W SMD0805 145071
R81 RES TF 47.5 1% .125W SMD0805 145128
R82 RES SMD0805 4.75K 1/8W 1% 145008
R83 RES TF 47.5 1% .125W SMD0805 145128
R84 RES TF 47.5 1% .125W SMD0805 145128
R85 RES TF 47.5 1% .125W SMD0805 145128
R86 RES TF 47.5 1% .125W SMD0805 145128
R87 RES TF 47.5 1% .125W SMD0805 145128
R88 RES TF 47.5 1% .125W SMD0805 145128
R89 RES SMD0805 1K 1/8W 1% 145007
R90 RES SMD0805 1K 1/8W 1% 145007
R91 RES TF 47.5 1% .125W SMD0805 145128
R92 RES MF 221 OHM 1% 1/4W 144559
R93 RES MF 221 OHM 1% 1/4W 144559
R94 RES MF 221 OHM 1% 1/4W 144559
R95 RES MF 221 OHM 1% 1/4W 144559
R96 RES FP 10 OHM 5% 1/4W 137105
R97 RES MF 1.5K 1% 1/4W 144539
R98 RES MF 1.5K 1% 1/4W 144539
R99 RES MF 1.5K 1% 1/4W 144539
R100 RES MF 1.5K 1% 1/4W 144539
R101 RES MF 1.5K 1% 1/4W 144539
R102 RES MF 1.5K 1% 1/4W 144539
R103 RES MF 3.32K 1% 1/4W 144518
R104 RES MF 3.32K 1% 1/4W 144518
R105 RES MF 3.32K 1% 1/4W 144518
R106 RES MF 3.32K 1% 1/4W 144518
R107 RES FP 10 OHM 5% 1/4W 137105
R108 RES MF 1.5K 1% 1/4W 144539
R109 RES MF 1.5K 1% 1/4W 144539
R110 RES SMD0805 33.2K 1/8W 1% 145033
R111 RES SMD0805 8.25K 1/8W 1% 145009
R112 RES MF 47.5K 1% 1/4W 144526
R113 RES MF 47.5K 1% 1/4W 144526
R114 RES MF 475 OHM 1% 1/4W 144509
R115 RES TF 100K 1% 0.1W SMD0805 145062

McIntosh C2600 Specifications

General

Signal to Noise Ratio	100dB
Phono Stage	Yes
Digital USB Input	1
Digital MCT Input	1
Vacuum Tube	Yes
Type	Tube Preamplifier
Frequency Response	20Hz - 20kHz (+0, -0.5dB)
Phono Inputs	1 Moving Magnet 1 Moving Coil
Outputs	3 Total
Output Impedance	100 ohms
Dimensions	17.5" (44.45cm) x 6" (15.24cm) x 18" (45.72cm)
Headphone Output	1/4" High Drive with Headphone Crossfeed Director (HXD®)
