McIntosh C2600 Service Manual

C2600
Ref. No. Description Part No.
DIGITAL PCB 751731 (Cont’d.)
Ref. No. Description Part No.
PARTS LIST (Cont’d.)
67
3
R116 RES MF 475 OHM 1% 1/4W 144509
R117 RES SMD0805 4.75K 1/8W 1% 145008
R118 RES SMD0805 4.75K 1/8W 1% 145008
R119 RES SMD0805 0 1/8W 0% 145016
R120 RES SMD0805 0 1/8W 0% 145016
R121 RES SMD0805 0 1/8W 0% 145016
R122 RES SMD0805 0 1/8W 0% 145016
S1 S2 SWITCH TACT 260GF 5MM SMD 150072
U1 IC CLOCK GENERATOR SMD 133869
U2 IC USB 2:1 MUX SWITCH SMD 133754
U3 IC EEPROM 256K BITS 3.3V SMD 133709
U4 IC USB AUDIO STREAMING SMD 133884
U5 IC QUAD 2-INPUT AND GATE SMD 133776
U6 IC SINGLE 2-INPUT AND GATE SMD 133502
U7 IC SINGLE 2-INPUT NOR GATE SMD 133500
U8 IC SNGLE 2-INPUT NAND GATE SMD 133501
U9 IC MICRO 32-BIT SAM4S SMD 133875
U10 IC 8 BIT DRIVER SMD 133461
U11 IC SNGLE 2-INPUT NAND GATE SMD 133501
U12 IC DIFFERENTIAL LINE RECR SMD 133693
U13 IC SINGLE 2-INPUT AND GATE SMD 133502
U14 IC SINGLE 2-INPUT AND GATE SMD 133502
U15 IC SINGLE NAND SCHMITT SMD 133724
U16 IC SINGLE NAND SCHMITT SMD 133724
U17 IC DIG INTERFACE RECEIVER SMD 133691
U18 IC SINGLE 2-INPUT AND GATE SMD 133502
U19 IC SINGLE 2 INPUT OR GATE SMD 133700
U20 IC QUAD 2 TO 1 DATA SELCTR SMD 133698
U21 IC SINGLE 2-INPUT NOR GATE SMD 133500
U22 IC SINGLE 2 INPUT OR GATE SMD 133700
U23 IC SINGLE 2 INPUT OR GATE SMD 133700
U24 IC SINGLE 2 INPUT OR GATE SMD 133700
U25 IC 2.5V 500mA LDO REGULAT SMD 133773
U26 IC CONVE S-RATE 32BIT 192K SMD 133765
U27 IC QUAD 2 TO 1 DATA SELCTR SMD 133698
U28 IC SINGLE NAND SCHMITT SMD 133724
U29 IC VOLTAGE REGULATOR 1.2V SMD 133696
U30 IC 32BIT 8 CH AUDIO DAC SMD 133818
U31 IC DUAL JFET OP AMP SMD 133778
U32 IC DUAL JFET OP AMP SMD 133778
U33 IC SINGLE 2-INPUT NOR GATE SMD 133500
U34 IC DUAL JFET OP AMP SMD 133778
U35 IC DUAL JFET OP AMP SMD 133778
Y1 CRYSTAL 24MHZ SMD 180102
Y2 CRYSTAL 12.00MHZ 20PF SMD 180103
Y3 CRYSTAL 27MHZ SMD 180100
Y4 CRYSTAL OSCLTOR 100MHZ SMD 180096
FIRMWARE V1.00 DIGITAL AUDIO 230097
FIRMWARE V1.00 HD USB AUDIO 230246
AUDIO PCB 751899
4
C1 CAP ELECT 10UF 50V 066445
C2 CAP ELECT 10UF 50V 066445
C3 CAP 10uF 20% 16V X5R SMD0805 061392
C4 CAP 10uF 20% 16V X5R SMD0805 061392
C5 CAP 10uF 20% 16V X5R SMD0805 061392
C6 CAP 10uF 20% 16V X5R SMD0805 061392
C7 CAP 10uF 20% 16V X5R SMD0805 061392
C8 CAP 10uF 20% 16V X5R SMD0805 061392
C9 CAP 10uF 20% 16V X5R SMD0805 061392
C10 CAP 10uF 20% 16V X5R SMD0805 061392
C11 CAP ELECT 10UF 50V 066445
C12 CAP ELECT 10UF 50V 066445
C13 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C14 CAP ELECT 10UF 50V 066445
C15 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C16 CAP 100pF 200V 5% SMD0805 061390
C17 CAP 100pF 200V 5% SMD0805 061390
C18 CAP 100pF 200V 5% SMD0805 061390
C19 CAP 100pF 200V 5% SMD0805 061390
C20 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C21 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C22 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C23 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C24 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C25 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C26 CAP ELECT 47UF 35V 066446
C27 CAP ELECT 47UF 35V 066446
C28 CAP ELECT 10UF 50V 066445
C29 CAP ELECT 10UF 50V 066445
C30 CAP ELECT 10UF 50V 066445
C31 CAP ELECT 10UF 50V 066445
C32 CAP ELECT 10UF 50V 066445
C33 CAP ELECT 10UF 50V 066445
C34 CAP 100pF 200V 5% SMD0805 061390
C35 CAP 100pF 200V 5% SMD0805 061390
C36 CAP 100pF 200V 5% SMD0805 061390
C37 CAP 100pF 200V 5% SMD0805 061390
C38 CAP 100pF 200V 5% SMD0805 061390
C39 CAP 100pF 200V 5% SMD0805 061390
C40 CAP 100pF 200V 5% SMD0805 061390
C41 CAP 100pF 200V 5% SMD0805 061390
C42 CAP 100pF 200V 5% SMD0805 061390
C43 CAP 100pF 200V 5% SMD0805 061390
C44 CAP 100pF 200V 5% SMD0805 061390
C45 CAP 100pF 200V 5% SMD0805 061390
C46 CAP 100pF 200V 5% SMD0805 061390
C47 CAP 100pF 200V 5% SMD0805 061390
C48 CAP 100pF 200V 5% SMD0805 061390
C49 CAP 100pF 200V 5% SMD0805 061390
C50 CAP 100pF 200V 5% SMD0805 061390
C51 CAP 100pF 200V 5% SMD0805 061390
C52 CAP ELECT 22UF 100V 066574
C53 CAP ELECT 22UF 100V 066574
C54 CAP ELECT 10UF 16V 066580
C55 CAP ELECT 10UF 16V 066580
C56 CAP ELECT 10UF 16V 066580
C57 CAP ELECT 10UF 16V 066580
C58 CAP ELECT 10UF 16V 066580
C59 CAP ELECT 10UF 16V 066580
C60 CAP ELECT 10UF 16V 066580
C61 CAP ELECT 10UF 16V 066580
C62 CAP ELECT 10UF 16V 066580
C63 CAP ELECT 10UF 16V 066580
C64 CAP ELECT 10UF 16V 066580
C65 CAP ELECT 10UF 16V 066580
C66 CAP 220pF 200V 10% NPO SMD0805 061369
C67 CAP 220pF 200V 10% NPO SMD0805 061369

McIntosh C2600 Specifications

General

Signal to Noise Ratio	100dB
Phono Stage	Yes
Digital USB Input	1
Digital MCT Input	1
Vacuum Tube	Yes
Type	Tube Preamplifier
Frequency Response	20Hz - 20kHz (+0, -0.5dB)
Phono Inputs	1 Moving Magnet 1 Moving Coil
Outputs	3 Total
Output Impedance	100 ohms
Dimensions	17.5" (44.45cm) x 6" (15.24cm) x 18" (45.72cm)
Headphone Output	1/4" High Drive with Headphone Crossfeed Director (HXD®)
