Ref. No. Description Part No.

AUDIO PCB 751899 (Cont’d.)

Ref. No. Description Part No.

PARTS LIST (Cont’d.)

C68 CAP 47pF 200V 10% NPO SMD0805 061368

C69 CAP 47pF 200V 10% NPO SMD0805 061368

C70 CAP 100pF 200V 5% SMD0805 061390

C71 CAP 100pF 200V 5% SMD0805 061390

C72 CAP 100pF 200V 5% SMD0805 061390

C73 CAP 100pF 200V 5% SMD0805 061390

C74 CAP 100pF 200V 5% SMD0805 061390

C75 CAP 100pF 200V 5% SMD0805 061390

C76 CAP 100pF 200V 5% SMD0805 061390

C77 CAP 100pF 200V 5% SMD0805 061390

C78 CAP 100pF 200V 5% SMD0805 061390

C79 CAP 100pF 200V 5% SMD0805 061390

C80 CAP 100pF 200V 5% SMD0805 061390

C81 CAP 100pF 200V 5% SMD0805 061390

C82 CAP 100pF 200V 5% SMD0805 061390

C83 CAP 100pF 200V 5% SMD0805 061390

C88 CAP ELECT 1000UF 25V 066513

C89 CAP ELECT 1000UF 25V 066513

C91 CAP ELECT 1000UF 25V 066513

C92 CAP NPO 1000pF 100V 5% SMD0805 061391

C93 CAP NPO 1000pF 100V 5% SMD0805 061391

C94 CAP NPO 1000pF 100V 5% SMD0805 061391

C95 CAP NPO 1000pF 100V 5% SMD0805 061391

C104 CAP ELECT 1UF 50V 066510

C105 CAP ELECT 1UF 50V 066510

C108 CAP NPO 1000pF 100V 5% SMD0805 061391

C109 CAP NPO 1000pF 100V 5% SMD0805 061391

C110 CAP NPO 1000pF 100V 5% SMD0805 061391

C111 CAP NPO 1000pF 100V 5% SMD0805 061391

C112 CAP MONO .1uF 50V +/-20% X7R SMD 061365

C115 CAP 10uF 20% 16V X5R SMD0805 061392

C116 CAP MONO .1uF 50V +/-20% X7R SMD 061365

C117 CAP ELECT 100UF 25V 066573

C124 CAP MONO .1uF 50V +/-20% X7R SMD 061365

C125 CAP ELECT 1UF 50V 066510

C126 CAP ELECT 1UF 50V 066510

C127 CAP MONO .1uF 50V +/-20% X7R SMD 061365

C128 CAP MONO .1uF 50V +/-20% X7R SMD 061365

C129 CAP MONO .1uF 50V +/-20% X7R SMD 061365

C131 CAP MONO .1uF 50V +/-20% X7R SMD 061365

C133 CAP 10uF 20% 16V X5R SMD0805 061392

C134 CAP ELECT 100UF 25V 066573

C135 CAP .47uF 50V 20% X7R SMD0805 061373

C136 CAP ELECT 10UF 50V 066445

C137 CAP 100pF 200V 5% SMD0805 061390

C138 CAP ELECT 10UF 50V 066445

C139 CAP MONO .1uF 50V +/-20% X7R SMD 061365

C140 CAP MONO .1uF 50V +/-20% X7R SMD 061365

C141 CAP MONO .1uF 50V +/-20% X7R SMD 061365

C142 CAP ELECT 10UF 50V 066445

C143 CAP .47uF 50V 20% X7R SMD0805 061373

C144 CAP MONO .1uF 50V +/-20% X7R SMD 061365

C145 CAP MONO .1uF 50V +/-20% X7R SMD 061365

C146 CAP ELECT 100UF 25V 066573

C147 CAP ELECT 100UF 25V 066573

C148 CAP 47pF 200V 10% NPO SMD0805 061368

C149 CAP 47pF 200V 10% NPO SMD0805 061368

C153 CAP .47uF 50V 20% X7R SMD0805 061373

C154 CAP .47uF 50V 20% X7R SMD0805 061373

C156 CAP MONO .1uF 50V +/-20% X7R SMD 061365

C157 CAP MONO .1uF 50V +/-20% X7R SMD 061365

C158 CAP ELECT 1000UF 25V 066513

C159 CAP ELECT 1000UF 25V 066513

C160 CAP MONO .1uF 50V +/-20% X7R SMD 061365

C161 CAP MONO .1uF 50V +/-20% X7R SMD 061365

C162 CAP MPF 0.22UF 5% 63VDC 064329

C163 CAP MPF 0.22UF 5% 63VDC 064329

C164 CAP MPF 0.22UF 5% 63VDC 064329

C165 CAP MPF 0.22UF 5% 63VDC 064329

C166 CAP 22uF 6.3V 20% SMD0805 061397

C167 CAP 22uF 6.3V 20% SMD0805 061397

C168 CAP 22uF 6.3V 20% SMD0805 061397

C169 CAP 470pF 100V 10% NPO SMD0805 061370

C170 CAP 470pF 100V 10% NPO SMD0805 061370

C171 CAP MONO .1uF 50V +/-20% X7R SMD 061365

C172 CAP MONO .1uF 50V +/-20% X7R SMD 061365

C173 CAP MPF 0.022UF 5% 63VDC 064316

C174 CAP ELECT 470UF 16V 066508

C175 CAP ELECT 470UF 16V 066508

C176 CAP MPF 0.022UF 5% 63VDC 064316

C177 CAP MONO .1uF 50V +/-20% X7R SMD 061365

C178 CAP MONO .1uF 50V +/-20% X7R SMD 061365

C179 CAP MONO .1uF 50V +/-20% X7R SMD 061365

C180 CAP MONO .1uF 50V +/-20% X7R SMD 061365

C181 CAP MONO .1uF 50V +/-20% X7R SMD 061365

C182 CAP ELECT 220UF 25V 066507

C183 CAP ELECT 220UF 25V 066507

C184 CAP ELECT 47UF 35V 066446

C185 CAP ELECT 47UF 35V 066446

C186 CAP .01uF 50V 20% X7R SMD0805 061372

C187 CAP .01uF 50V 20% X7R SMD0805 061372

C188 CAP MONO .1uF 50V +/-20% X7R SMD 061365

C189 CAP MONO .1uF 50V +/-20% X7R SMD 061365

C190 CAP .47uF 50V 20% X7R SMD0805 061373

C191 CAP .47uF 50V 20% X7R SMD0805 061373

C194 CAP ELECT 1000UF 25V 066513

C201 CAP MPF 0.0022UF 5% 63VDC 064454

C202 CAP 10uF 20% 16V X5R SMD0805 061392

C203 CAP MPF 1UF 5% 63VDC 064337

C204 CAP MPF 0.22UF 5% 63VDC 064329

C205 CAP ELECT 100UF 25V 066573

C207 CAP 10uF 20% 16V X5R SMD0805 061392

C206 CAP 220pF 200V 10% NPO SMD0805 061369

C208 CAP MPF 0.22UF 5% 63VDC 064329

C209 CAP MPF 1UF 5% 63VDC 064337

C210 CAP MPF 0.0022UF 5% 63VDC 064454

C211 CAP ELECT 10UF 50V 066445

C212 CAP MONO .1uF 50V +/-20% X7R SMD 061365

C213 CAP MONO .1uF 50V +/-20% X7R SMD 061365

C214 CAP ELECT 10UF 50V 066445

C215 CAP ELECT 1000UF 25V 066513

C216 CAP ELECT 1000UF 25V 066513

C217 CAP ELECT 1000UF 25V 066513

C218 CAP ELECT 1000UF 25V 066513

D1 DIODE ESD SUPPRESSOR SMD 070198

D2 DIODE ESD SUPPRESSOR SMD 070198

D3 DIODE ESD SUPPRESSOR SMD 070198

D4 DIODE ESD SUPPRESSOR SMD 070198
