McIntosh C2600 Service Manual

C2600
69
Ref. No. Description Part No.
AUDIO PCB 751899 (Cont’d.)
Ref. No. Description Part No.
PARTS LIST (Cont’d.)
4
D5 DIODE ESD SUPPRESSOR SMD 070198
D6 DIODE ESD SUPPRESSOR SMD 070198
D7 DIODE ESD SUPPRESSOR SMD 070198
D8 DIODE ESD SUPPRESSOR SMD 070198
D9 DIODE SMALL SIGNAL 4148 SMD 070199
D10 DIODE SMALL SIGNAL 4148 SMD 070199
D11 DIODE SMALL SIGNAL 4148 SMD 070199
D12 DIODE SMALL SIGNAL 4148 SMD 070199
D13 DIODE SMALL SIGNAL 4148 SMD 070199
D14 DIODE SMALL SIGNAL 4148 SMD 070199
D15 DIODE SMALL SIGNAL 4148 SMD 070199
D16 DIODE SMALL SIGNAL 4148 SMD 070199
D17 DIODE SMALL SIGNAL 4148 SMD 070199
D18 DIODE SMALL SIGNAL 4148 SMD 070199
D19 DIODE SMALL SIGNAL 4148 SMD 070199
D20 DIODE SMALL SIGNAL 4148 SMD 070199
D21 DIODE ESD SUPPRESSOR SMD 070198
D22 DIODE ESD SUPPRESSOR SMD 070198
D23 DIODE ESD SUPPRESSOR SMD 070198
D24 DIODE ESD SUPPRESSOR SMD 070198
D25 DIODE SMALL SIGNAL 4148 SMD 070199
D26 DIODE SMALL SIGNAL 4148 SMD 070199
D28 DIODE SMALL SIGNAL 4148 SMD 070199
D29 DIODE SMALL SIGNAL 4148 SMD 070199
D30 DIODE ZENER 5.1V 5% SMD 070215
D31 DIODE ZENER 5.1V 5% SMD 070215
D32 DIODE ZENER 5.1V 5% SMD 070215
D33 DIODE SMALL SIGNAL 4148 SMD 070199
D34 DIODE SMALL SIGNAL 4148 SMD 070199
D35 DIODE SMALL SIGNAL 4148 SMD 070199
D36 DIODE SMALL SIGNAL 4148 SMD 070199
D37 DIODE SMALL SIGNAL 4148 SMD 070199
D38 DIODE SMALL SIGNAL 4148 SMD 070199
D39 DIODE SMALL SIGNAL 4148 SMD 070199
D40 DIODE SMALL SIGNAL 4148 SMD 070199
D41 DIODE SMALL SIGNAL 4148 SMD 070199
D42 DIODE SMALL SIGNAL 4148 SMD 070199
D43 DIODE SMALL SIGNAL 4148 SMD 070199
D44 DIODE SMALL SIGNAL 4148 SMD 070199
D45 DIODE ESD SUPPRESSOR SMD 070198
D46 DIODE ESD SUPPRESSOR SMD 070198
D47 DIODE ESD SUPPRESSOR SMD 070198
D48 DIODE ESD SUPPRESSOR SMD 070198
D49 DIODE ESD SUPPRESSOR SMD 070198
D50 DIODE ESD SUPPRESSOR SMD 070198
D51 DIODE ESD SUPPRESSOR SMD 070198
D52 DIODE ESD SUPPRESSOR SMD 070198
D53 DIODE ESD SUPPRESSOR SMD 070198
D54 DIODE ESD SUPPRESSOR SMD 070198
D55 DIODE ESD SUPPRESSOR SMD 070198
D56 DIODE ESD SUPPRESSOR SMD 070198
D57 DIODE ESD SUPPRESSOR SMD 070198
D58 DIODE ESD SUPPRESSOR SMD 070198
D59 DIODE ZENER 5.1V 5% SMD 070215
D60 DIODE SMALL SIGNAL 4148 SMD 070199
D61 DIODE SMALL SIGNAL 4148 SMD 070199
D62 DIODE SMALL SIGNAL 4148 SMD 070199
D63 DIODE SMALL SIGNAL 4148 SMD 070199
D64 DIODE ZENER 5.1V 5% SMD 070215
J1 JACK DUAL RCA 118020
J2 JACK DUAL RCA 118020
J3 JACK DUAL RCA 118020
J4 JACK DUAL RCA 118020
J5 CONN 12 PIN FFC SMD 118001
J6 JACK DUAL RCA 118020
J7 RECEPTACLE XLR FEMALE 117685
J8 RECEPTACLE XLR FEMALE 117685
J9 RECEPTACLE XLR FEMALE 117685
J10 RECEPTACLE XLR FEMALE 117685
J11 RECEPTACLE XLR FEMALE 117685
J12 RECEPTACLE XLR FEMALE 117685
J13 JACK DUAL RCA 118020
J14 JACK DUAL RCA 118020
J15 CONN 18 PIN FFC SMD 118003
J16 CONN 12 PIN FFC SMD 118001
J17 CONN 18 PIN FFC SMD 118003
J18 CONN 12 PIN FFC RA SMD 117990
J27 CONN 12 PIN FFC RA SMD 117990
J28 CONN 12 PIN FFC SMD 118001
J32 HEADER 2 PIN LATCHING 117766
J122 HEADER 2 PIN LATCHING 117766
J123 HEADER 2 PIN LATCHING 117766
J124 HEADER 2 PIN LATCHING 117766
K1 RELAY REED DPST-NO 1.2A 5VDC 087089
K2 RELAY REED DPST-NO 1.2A 5VDC 087089
K3 RELAY REED DPST-NO 1.2A 5VDC 087089
K4 RELAY REED DPST-NO 1.2A 5VDC 087089
K5 RELAY REED DPST-NO 1.2A 5VDC 087089
K6 RELAY REED DPST-NO 1.2A 5VDC 087089
K7 RELAY REED DPST-NO 1.2A 5VDC 087089
K8 RELAY REED DPST-NO 1.2A 5VDC 087089
K9 RELAY REED DPST-NO 1.2A 5VDC 087089
K10 RELAY REED DPST-NO 1.2A 5VDC 087089
K11 RELAY REED SPST-NO 5V 1.2A 087078
K12 RELAY REED FORM 1C 5V 125 OHM 087056
K13 RELAY REED FORM 1C 5V 125 OHM 087056
K16 RELAY REED DPST-NO 1.2A 5VDC 087089
K17 RELAY REED DPST-NO 1.2A 5VDC 087089
L1 FERRITE 600 OHM 1 AMP SMD 076026
L2 FERRITE 600 OHM 1 AMP SMD 076026
L3 FERRITE 600 OHM 1 AMP SMD 076026
L4 FERRITE 600 OHM 1 AMP SMD 076026
PCB1 PC BD AUDIO 130341
Q1 TRANSISTOR NPN 2SC4694 SMD 132336
Q2 TRANSISTOR NPN 2SC4694 SMD 132336
Q3 TRANSISTOR NPN 2SC4694 SMD 132336
Q4 TRANSISTOR NPN 2SC4694 SMD 132336
Q5 TRANSISTOR NPN 2SC4694 SMD 132336
Q6 TRANSISTOR NPN 2SC4694 SMD 132336
Q7 TRANSISTOR NPN 2SC4694 SMD 132336
Q8 TRANSISTOR NPN 2SC4694 SMD 132336
Q9 TRANSISTOR NPN 2SC4694 SMD 132336
Q10 TRANSISTOR NPN 2SC4694 SMD 132336
Q11 TRANSISTOR NPN 2SC4694 SMD 132336
Q12 TRANSISTOR NPN 2SC4694 SMD 132336
Q13 TRANSISTOR NPN 2SC4694 SMD 132336
Q14 TRANSISTOR NPN 2SC4694 SMD 132336
Q15 TRANSISTOR NPN 2SC4694 SMD 132336

McIntosh C2600 Specifications

General

Signal to Noise Ratio	100dB
Phono Stage	Yes
Digital USB Input	1
Digital MCT Input	1
Vacuum Tube	Yes
Type	Tube Preamplifier
Frequency Response	20Hz - 20kHz (+0, -0.5dB)
Phono Inputs	1 Moving Magnet 1 Moving Coil
Outputs	3 Total
Output Impedance	100 ohms
Dimensions	17.5" (44.45cm) x 6" (15.24cm) x 18" (45.72cm)
Headphone Output	1/4" High Drive with Headphone Crossfeed Director (HXD®)
