McIntosh C2600 Service Manual

70
Ref. No. Description Part No.
AUDIO PCB 751899 (Cont’d.)
Ref. No. Description Part No.
PARTS LIST (Cont’d.)
4
Q16 TRANSISTOR NPN 2SC4694 SMD 132336
Q17 TRANSISTOR PNP A55 SMD 132334
Q18 TRANSISTOR NPN A05 SMD 132333
Q19 TRANSISTOR PNP A55 SMD 132334
Q20 TRANSISTOR NPN A05 SMD 132333
Q21 TRANSISTOR PNP A55 SMD 132334
Q22 TRANSISTOR NPN A05 SMD 132333
Q23 TRANSISTOR PNP A55 SMD 132334
Q24 TRANSISTOR NPN A05 SMD 132333
Q25 TRANSISTOR PNP A55 SMD 132334
Q26 TRANSISTOR NPN A05 SMD 132333
Q27 TRANSISTOR PNP A55 SMD 132334
Q28 TRANSISTOR NPN A05 SMD 132333
Q29 TRANSISTOR PNP A55 SMD 132334
Q30 TRANSISTOR NPN A05 SMD 132333
Q31 TRANSISTOR PNP A55 SMD 132334
Q32 TRANSISTOR NPN A05 SMD 132333
Q33 TRANSISTOR PNP A55 SMD 132334
Q34 TRANSISTOR NPN A05 SMD 132333
Q35 TRANSISTOR PNP A55 SMD 132334
Q36 TRANSISTOR NPN A05 SMD 132333
Q37 TRANSISTOR NPN A05 SMD 132333
Q38 TRANSISTOR PNP A55 SMD 132334
Q39 TRANSISTOR NPN A05 SMD 132333
Q40 TRANSISTOR PNP A55 SMD 132334
Q41 TRANSISTOR NPN A05 SMD 132333
Q42 TRANSISTOR NPN 2SC5994 SMD 132341
Q43 TRANSISTOR PNP SMD 132340
Q44 TRANSISTOR NPN 2SC5994 SMD 132341
Q45 TRANSISTOR PNP SMD 132340
Q46 TRANSISTOR NPN A05 SMD 132333
Q47 TRANSISTOR NPN A05 SMD 132333
Q48 TRANSISTOR NPN A05 SMD 132333
Q49 TRANSISTOR NPN A05 SMD 132333
Q50 TRANSISTOR NPN A05 SMD 132333
Q51 TRANSISTOR NPN A05 SMD 132333
Q52 TRANSISTOR NPN A05 SMD 132333
Q53 TRANSISTOR NPN A05 SMD 132333
Q54 TRANSISTOR NPN A05 SMD 132333
Q55 TRANSISTOR NPN A05 SMD 132333
Q56 TRANSISTOR NPN A05 SMD 132333
Q57 TRANSISTOR NPN A05 SMD 132333
Q59 TRANSISTOR NPN A05 SMD 132333
Q60 TRANSISTOR NPN A05 SMD 132333
Q61 TRANSISTOR NPN A05 SMD 132333
Q62 TRANSISTOR NPN A05 SMD 132333
Q63 TRANSISTOR NPN A05 SMD 132333
Q64 TRANSISTOR NPN A05 SMD 132333
Q65 TRANSISTOR NPN 2SC3324 SMD 132345
Q66 TRANSISTOR NPN 2SC3324 SMD 132345
Q67 TRANSISTOR NPN 2SC3324 SMD 132345
Q68 TRANSISTOR NPN 2SC3324 SMD 132345
Q69 TRANSISTOR NPN A05 SMD 132333
Q70 TRANSISTOR NPN A05 SMD 132333
Q200 TRANS PNP W/R1R2 10K/10K SMD 132348
Q201 TRANS PNP W/R1R2 10K/10K SMD 132348
Q202 TRANS PNP W/R1R2 10K/10K SMD 132348
Q203 TRANS PNP W/R1R2 10K/10K SMD 132348
R1 RES TF 47.5K 1% 0.125W SMD0805 145132
R2 RES TF 47.5K 1% 0.125W SMD0805 145132
R3 RES TF 47.5K 1% 0.125W SMD0805 145132
R4 RES TF 47.5K 1% 0.125W SMD0805 145132
R5 RES TF 47.5K 1% 0.125W SMD0805 145132
R6 RES TF 47.5K 1% 0.125W SMD0805 145132
R7 RES TF 47.5K 1% 0.125W SMD0805 145132
R8 RES TF 47.5K 1% 0.125W SMD0805 145132
R9 RES TF 100K 1% 0.1W SMD0805 145062
R10 RES TF 100K 1% 0.1W SMD0805 145062
R11 RES TF 100K 1% 0.1W SMD0805 145062
R12 RES TF 100K 1% 0.1W SMD0805 145062
R13 RES TF 100K 1% 0.1W SMD0805 145062
R14 RES TF 100K 1% 0.1W SMD0805 145062
R15 RES TF 100K 1% 0.1W SMD0805 145062
R16 RES TF 100K 1% 0.1W SMD0805 145062
R17 RES TF 100K 1% 0.1W SMD0805 145062
R18 RES TF 100K 1% 0.1W SMD0805 145062
R19 RES TF 100K 1% 0.1W SMD0805 145062
R20 RES TF 100K 1% 0.1W SMD0805 145062
R21 RES MF 2.21 OHM 1% 1/4W 144607
R22 RES MF 2.21 OHM 1% 1/4W 144607
R23 RES TF 221K .125W .5% SMD0805 145140
R24 RES TF 221K .125W .5% SMD0805 145140
R25 RES TF 1K 1% 0.1W SMD0805 145117
R26 RES TF 1K 1% 0.1W SMD0805 145117
R27 RES SMD0805 4.75K 1/8W 1% 145008
R28 RES SMD0805 4.75K 1/8W 1% 145008
R29 RES TF 100K 1% 0.1W SMD0805 145062
R30 RES TF 100K 1% 0.1W SMD0805 145062
R31 RES TF 100K 1% 0.1W SMD0805 145062
R32 RES TF 100K 1% 0.1W SMD0805 145062
R33 RES TF 100K 1% 0.1W SMD0805 145062
R34 RES TF 100K 1% 0.1W SMD0805 145062
R35 RES TF 10K 1% 0.1W SMD0805 145061
R36 RES TF 10K 1% 0.1W SMD0805 145061
R37 RES TF 10K 1% 0.1W SMD0805 145061
R38 RES TF 10K 1% 0.1W SMD0805 145061
R39 RES TF 10K 1% 0.1W SMD0805 145061
R40 RES TF 10K 1% 0.1W SMD0805 145061
R41 RES TF 10K 1% 0.1W SMD0805 145061
R42 RES TF 10K 1% 0.1W SMD0805 145061
R43 RES TF 10K 1% 0.1W SMD0805 145061
R44 RES TF 10K 1% 0.1W SMD0805 145061
R45 RES TF 10K 1% 0.1W SMD0805 145061
R46 RES TF 10K 1% 0.1W SMD0805 145061
R47 RES SMD0805 22.1K 1/8W 1% 145012
R48 RES SMD0805 22.1K 1/8W 1% 145012
R49 RES SMD0805 22.1K 1/8W 1% 145012
R50 RES SMD0805 22.1K 1/8W 1% 145012
R51 RES SMD0805 22.1K 1/8W 1% 145012
R52 RES SMD0805 22.1K 1/8W 1% 145012
R53 RES SMD0805 22.1K 1/8W 1% 145012
R54 RES SMD0805 22.1K 1/8W 1% 145012
R55 RES SMD0805 22.1K 1/8W 1% 145012
R56 RES SMD0805 22.1K 1/8W 1% 145012
R57 RES SMD0805 22.1K 1/8W 1% 145012
R58 RES SMD0805 22.1K 1/8W 1% 145012
R59 RES SMD0805 22.1K 1/8W 1% 145012
R60 RES SMD0805 22.1K 1/8W 1% 145012

McIntosh C2600 Specifications

General

Signal to Noise Ratio	100dB
Phono Stage	Yes
Digital USB Input	1
Digital MCT Input	1
Vacuum Tube	Yes
Type	Tube Preamplifier
Frequency Response	20Hz - 20kHz (+0, -0.5dB)
Phono Inputs	1 Moving Magnet 1 Moving Coil
Outputs	3 Total
Output Impedance	100 ohms
Dimensions	17.5" (44.45cm) x 6" (15.24cm) x 18" (45.72cm)
Headphone Output	1/4" High Drive with Headphone Crossfeed Director (HXD®)
