McIntosh C2600 Service Manual

C2600
71
Ref. No. Description Part No.
AUDIO PCB 751899 (Cont’d.)
Ref. No. Description Part No.
PARTS LIST (Cont’d.)
4
R61 RES SMD0805 22.1K 1/8W 1% 145012
R62 RES SMD0805 22.1K 1/8W 1% 145012
R63 RES TF 100K 1% 0.1W SMD0805 145062
R64 RES TF 100K 1% 0.1W SMD0805 145062
R65 RES TF 100K 1% 0.1W SMD0805 145062
R66 RES TF 100K 1% 0.1W SMD0805 145062
R67 RES TF 100K 1% 0.1W SMD0805 145062
R68 RES TF 100K 1% 0.1W SMD0805 145062
R69 RES TF 215 1% 0.1W SMD0805 145073
R70 RES TF 215 1% 0.1W SMD0805 145073
R71 RES TF 100K 1% 0.1W SMD0805 145062
R72 RES TF 100K 1% 0.1W SMD0805 145062
R73 RES TF 100K 1% 0.1W SMD0805 145062
R74 RES TF 100K 1% 0.1W SMD0805 145062
R75 RES TF 100K 1% 0.1W SMD0805 145062
R76 RES TF 100K 1% 0.1W SMD0805 145062
R77 RES TF 47.5K 1% 0.125W SMD0805 145132
R78 RES TF 47.5K 1% 0.125W SMD0805 145132
R79 RES TF 360 1% 0.1W SMD0805 145081
R80 RES TF 360 1% 0.1W SMD0805 145081
R81 RES MF 51.1 OHM 2% 1/4W 144720
R82 RES MF 51.1 OHM 2% 1/4W 144720
R83 RES TF 1K 1% 0.1W SMD0805 145117
R84 RES TF 1K 1% 0.1W SMD0805 145117
R85 RES SMD0805 4.75K 1/8W 1% 145008
R86 RES TF 47.5K 1% 0.125W SMD0805 145132
R87 RES MF 110 OHM 1% 1/4W 144664
R88 RES MF 110 OHM 1% 1/4W 144664
R89 RES TF 1K 1% 0.1W SMD0805 145117
R90 RES TF 1K 1% 0.1W SMD0805 145117
R91 RES SMD0805 4.75K 1/8W 1% 145008
R92 RES TF 47.5K 1% 0.125W SMD0805 145132
R93 RES MF 249 OHM 1% 1/4W 144721
R94 RES MF 249 OHM 1% 1/4W 144721
R95 RES TF 1K 1% 0.1W SMD0805 145117
R96 RES TF 1K 1% 0.1W SMD0805 145117
R97 RES SMD0805 4.75K 1/8W 1% 145008
R98 RES TF 47.5K 1% 0.125W SMD0805 145132
R99 RES MF 681 OHM 1% 1/4W 144567
R100 RES MF 681 OHM 1% 1/4W 144567
R101 RES TF 1K 1% 0.1W SMD0805 145117
R102 RES TF 1K 1% 0.1W SMD0805 145117
R103 RES SMD0805 4.75K 1/8W 1% 145008
R104 RES TF 1K 1% 0.1W SMD0805 145117
R105 RES TF 1K 1% 0.1W SMD0805 145117
R106 RES TF 47.5K 1% 0.125W SMD0805 145132
R107 RES TF 2K 1% 0.1W SMD0805 145115
R108 RES TF 2K 1% 0.1W SMD0805 145115
R109 RES TF 2K 1% 0.1W SMD0805 145115
R110 RES TF 2K 1% 0.1W SMD0805 145115
R111 RES TF 10 1% 0.1W SMD0805 145063
R112 RES TF 10 1% 0.1W SMD0805 145063
R113 RES TF 10 1% 0.1W SMD0805 145063
R114 RES TF 10 1% 0.1W SMD0805 145063
R121 RES TF 221K .125W .5% SMD0805 145140
R122 RES TF 221K .125W .5% SMD0805 145140
R125 RES TF 240 1% 0.1W SMD0805 145075
R126 RES TF 240 1% 0.1W SMD0805 145075
R127 RES TF 240 1% 0.1W SMD0805 145075
R128 RES TF 240 1% 0.1W SMD0805 145075
R129 RES SMD0805 4.75K 1/8W 1% 145008
R130 RES SMD0805 4.75K 1/8W 1% 145008
R131 RES SMD0805 4.75K 1/8W 1% 145008
R132 RES SMD0805 4.75K 1/8W 1% 145008
R135 RES SMD0805 475 1/8W 1% 145020
R140 RES SMD0805 4.75K 1/8W 1% 145008
R141 RES TF 221K .125W .5% SMD0805 145140
R142 RES TF 221K .125W .5% SMD0805 145140
R143 RES SMD0805 4.75K 1/8W 1% 145008
R146 RES SMD0805 475 1/8W 1% 145020
R147 RES SMD0805 4.75K 1/8W 1% 145008
R148 RES TF 100K 1% 0.1W SMD0805 145062
R149 RES SMD0805 4.75K 1/8W 1% 145008
R150 RES SMD0805 2.21M 1/8W 1% 145043
R151 RES SMD0805 3.32K 1/8W 1% 145026
R152 RES TF 100K 1% 0.1W SMD0805 145062
R153 RES SMD0805 3.32K 1/8W 1% 145026
R154 RES SMD0805 3.32K 1/8W 1% 145026
R155 RES SMD0805 3.32K 1/8W 1% 145026
R156 RES TF 10K 1% 0.1W SMD0805 145061
R157 RES TF 1K 1% 0.1W SMD0805 145117
R158 RES TF 1K 1% 0.1W SMD0805 145117
R159 RES TF 10K 1% 0.1W SMD0805 145061
R160 RES TF 100K 1% 0.1W SMD0805 145062
R165 RES TF 221K .125W .5% SMD0805 145140
R166 RES TF 221K .125W .5% SMD0805 145140
R171 RES FP 10 OHM 5% 1/4W 137105
R172 RES FP 10 OHM 5% 1/4W 137105
R173 RES TF 499 1% 0.1W SMD0805 145084
R174 RES TF 1M 1% 0.125W SMD0805 145131
R175 RES TF 1M 1% 0.125W SMD0805 145131
R176 RES TF 499 1% 0.1W SMD0805 145084
R177 RES TF 2K 1% 0.1W SMD0805 145115
R178 RES TF 2K 1% 0.1W SMD0805 145115
R179 RES TF 49.9K 1% 0.1W SMD0805 145085
R180 RES TF 49.9K 1% 0.1W SMD0805 145085
R181 RES TF 2K 1% 0.1W SMD0805 145115
R182 RES TF 2K 1% 0.1W SMD0805 145115
R183 RES TF 2K 1% 0.1W SMD0805 145115
R184 RES TF 2K 1% 0.1W SMD0805 145115
R185 RES TF 2K 1% 0.1W SMD0805 145115
R186 RES SMD0805 4.75K 1/8W 1% 145008
R187 RES SMD0805 4.75K 1/8W 1% 145008
R188 RES SMD0805 4.75K 1/8W 1% 145008
R189 RES SMD0805 4.75K 1/8W 1% 145008
R190 RES TF 10 1% 0.1W SMD0805 145063
R191 RES TF 10 1% 0.1W SMD0805 145063
R192 RES TF 10 1% 0.1W SMD0805 145063
R193 RES TF 10 1% 0.1W SMD0805 145063
R194 RES TF 10K 1% 0.1W SMD0805 145061
R196 RES TF 10K 1% 0.1W SMD0805 145061
R195 RES TF 49.9 1% 0.1W SMD0805 145086
R197 RES TF 49.9 1% 0.1W SMD0805 145086
R198 RES TF 95.3 1% 0.1W SMD0805 145093
R199 RES TF 95.3 1% 0.1W SMD0805 145093
R200 RES TF 95.3 1% 0.1W SMD0805 145093
R201 RES TF 95.3 1% 0.1W SMD0805 145093
R202 RES SMD0805 5.62K 1/8W 1% 145028

McIntosh C2600 Specifications

General

Signal to Noise Ratio	100dB
Phono Stage	Yes
Digital USB Input	1
Digital MCT Input	1
Vacuum Tube	Yes
Type	Tube Preamplifier
Frequency Response	20Hz - 20kHz (+0, -0.5dB)
Phono Inputs	1 Moving Magnet 1 Moving Coil
Outputs	3 Total
Output Impedance	100 ohms
Dimensions	17.5" (44.45cm) x 6" (15.24cm) x 18" (45.72cm)
Headphone Output	1/4" High Drive with Headphone Crossfeed Director (HXD®)
