McIntosh C2600 Service Manual

72
Ref. No. Description Part No.
AUDIO PCB 751899 (Cont’d.)
Ref. No. Description Part No.
PARTS LIST (Cont’d.)
4
R203 RES SMD0805 5.62K 1/8W 1% 145028
R204 RES SMD0805 1.5K 1/8W 1% 145022
R205 RES SMD0805 1.5K 1/8W 1% 145022
R206 RES SMD0805 5.62K 1/8W 1% 145028
R207 RES TF 1K 1% 0.1W SMD0805 145117
R208 RES SMD0805 5.62K 1/8W 1% 145028
R211 RES SMD0805 5.62K 1/8W 1% 145028
R212 RES SMD0805 5.62K 1/8W 1% 145028
R213 RES SMD0805 5.62K 1/8W 1% 145028
R214 RES SMD0805 5.62K 1/8W 1% 145028
R215 RES SMD0805 22.1K 1/8W 1% 145012
R217 RES TF 100K 1% 0.1W SMD0805 145062
R218 RES SMD0805 5.62K 1/8W 1% 145028
R219 RES SMD0805 3.32K 1/8W 1% 145026
R220 RES SMD0805 3.32K 1/8W 1% 145026
R221 RES SMD0805 3.32K 1/8W 1% 145026
R222 RES TF 47.5 1% .125W SMD0805 145128
R223 RES TF 47.5 1% .125W SMD0805 145128
R224 RES TF 1K 1% 0.1W SMD0805 145117
R225 RES TF 1K 1% 0.1W SMD0805 145117
R226 RES TF 1K 1% 0.1W SMD0805 145117
R227 RES TF 1K 1% 0.1W SMD0805 145117
R228 RES SMD0805 68.1K 1/8W 1% 145035
R229 RES SMD0805 68.1K 1/8W 1% 145035
R230 RES SMD0805 68.1K 1/8W 1% 145035
R231 RES SMD0805 68.1K 1/8W 1% 145035
R232 RES TF 10 1% 0.1W SMD0805 145063
R233 RES TF 10 1% 0.1W SMD0805 145063
R234 RES SMD0805 22.1K 1/8W 1% 145012
R235 RES SMD0805 22.1K 1/8W 1% 145012
R236 RES SMD0805 332K 1/8W 1% 145039
R237 RES SMD0805 332K 1/8W 1% 145039
R238 RES SMD0805 221 1/8W 1% 145001
R239 RES SMD0805 221 1/8W 1% 145001
R240 RES SMD0805 2.21M 1/8W 1% 145043
R241 RES SMD0805 2.21M 1/8W 1% 145043
R242 POT TRIM 100K VERT SMD 134522
R243 POT TRIM 100K VERT SMD 134522
R244 RES SMD0805 3.32K 1/8W 1% 145026
R245 RES SMD0805 3.32K 1/8W 1% 145026
R246 RES SMD0805 68.1K 1/8W 1% 145035
R247 RES SMD0805 68.1K 1/8W 1% 145035
R248 RES TF 10 1% 0.1W SMD0805 145063
R249 RES TF 10 1% 0.1W SMD0805 145063
R250 RES TF 100K 1% 0.1W SMD0805 145062
R251 RES TF 100K 1% 0.1W SMD0805 145062
R252 RES TF 100K 1% 0.1W SMD0805 145062
R253 RES TF 10K 1% 0.1W SMD0805 145061
R254 RES TF 10K 1% 0.1W SMD0805 145061
R255 RES TF 10K 1% 0.1W SMD0805 145061
R256 RES TF 10K 1% 0.1W SMD0805 145061
R257 RES TF 10K 1% 0.1W SMD0805 145061
R258 RES TF 10K 1% 0.1W SMD0805 145061
R259 RES TF 10K 1% 0.1W SMD0805 145061
R260 RES TF 10K 1% 0.1W SMD0805 145061
R261 RES TF 47.5K 1% 0.125W SMD0805 145132
R262 RES TF 47.5K 1% 0.125W SMD0805 145132
R263 RES TF 47.5K 1% 0.125W SMD0805 145132
R264 RES TF 47.5K 1% 0.125W SMD0805 145132
R269 RES SMD0805 4.75K 1/8W 1% 145008
R270 RES SMD0805 332 1/8W 1% 145006
R271 RES SMD0805 3.92K 1/8W 1% 145027
R272 RES TF 1K 1% 0.1W SMD0805 145117
R273 RES TF 1K 1% 0.1W SMD0805 145117
R274 RES SMD0805 4.75K 1/8W 1% 145008
R275 RES SMD0805 332 1/8W 1% 145006
R276 RES SMD0805 3.92K 1/8W 1% 145027
R277 RES TF 47.5 1% .125W SMD0805 145128
U1 IC DUAL OD AMP 5532 SMD 133718
U2 IC DUAL OD AMP 5532 SMD 133718
U3 IC DUAL OD AMP 5532 SMD 133718
U4 IC DUAL OD AMP 5532 SMD 133718
U7 IC OP AMP LOW NOISE 5534 SMD 133719
U8 IC OP AMP LOW NOISE 5534 SMD 133719
U9 IC REG POS ADJ 1.5A SMD 133822
U10 IC 8 BIT DRIVER SMD 133461
U13 IC REG NEG ADJ 1.5A SMD 133821
U14 IC OP AMP 33178 SMD 133720
U15 IC SINGLE NAND SCHMITT SMD 133724
U16 IC 2CHANNEL VOLUME CNTRL SMD 133779
U17 IC DUAL JFET OP AMP SMD 133778
U18 IC DUAL AMP 5532 SMD 133718
U19 IC DUAL AMP 5532 SMD 133718
U20 IC 8 BIT DRIVER SMD 133461
U21 IC 8 BIT DRIVER SMD 133461
U22 IC SINGLE NAND SCHMITT SMD 133724
U23 IC 8 BIT DRIVER SMD 133461
U24 IC OP AMP 33178 SMD 133720
U25 IC OP AMP 33178 SMD 133720
U26 IC TONE CONTROL 3-BAND SMD 133668
DSPLY/L PSHBTN/R PSHBTN/HDPHN/L MTR/R MTR PCB 751900
5
6
7
8
9
10
C1 CAP ELECT 10UF 50V SMD 066602
C2 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C3 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C4 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C5 CAP ELECT 10UF 50V SMD 066602
C6 CAP ELECT 10UF 50V SMD 066602
C7 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C8 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C9 CAP NPO 1000pF 100V 5% SMD0805 061391
C10 CAP NPO 1000pF 100V 5% SMD0805 061391
C11 CAP ELECT 100UF 25V SMD 066605
C12 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C13 CAP MONO .1uF 50V +/-20% X7R SMD 061365
D1 DIODE SMALL SIGNAL 4148 SMD 070199
DS1 LED RED HIGH EFFICIENCY 5MM 058207
DS2 LED RED HIGH EFFICIENCY 5MM 058207
DS3 LED RED HIGH EFFICIENCY 5MM 058207
DS4 LED RED HIGH EFFICIENCY 5MM 058207
DS5 ASSY VFD W/ SPACERS CAP TAPE PT 751926
DS7 LED GRN REV MOUNT SMD 058212
DS8 LED GRN REV MOUNT SMD 058212
DS9 LED GRN REV MOUNT SMD 058212
DS10 LED GRN REV MOUNT SMD 058212
DS11 LED GRN REV MOUNT SMD 058212
DS12 LED GRN REV MOUNT SMD 058212
DS13 LED GRN REV MOUNT SMD 058212

McIntosh C2600 Specifications

General

Signal to Noise Ratio	100dB
Phono Stage	Yes
Digital USB Input	1
Digital MCT Input	1
Vacuum Tube	Yes
Type	Tube Preamplifier
Frequency Response	20Hz - 20kHz (+0, -0.5dB)
Phono Inputs	1 Moving Magnet 1 Moving Coil
Outputs	3 Total
Output Impedance	100 ohms
Dimensions	17.5" (44.45cm) x 6" (15.24cm) x 18" (45.72cm)
Headphone Output	1/4" High Drive with Headphone Crossfeed Director (HXD®)
