McIntosh C2600 Service Manual

C2600
73
Ref. No. Description Part No.
DSPLY/L PSHBTN/R PSHBTN/HDPHN/L MTR/R MTR PCB 751900 (Cont’d.)
Ref. No. Description Part No.
PARTS LIST (Cont’d.)
5
6
7
8
9
10
DS14 LED GRN REV MOUNT SMD 058212
DS15 LED GRN REV MOUNT SMD 058212
DS16 LED GRN REV MOUNT SMD 058212
DS17 LED GRN REV MOUNT SMD 058212
DS18 LED GRN REV MOUNT SMD 058212
DS19 LED GRN REV MOUNT SMD 058212
DS20 LED GRN REV MOUNT SMD 058212
DS21 LED GRN REV MOUNT SMD 058212
DS22 LED GRN REV MOUNT SMD 058212
DS23 LED GRN REV MOUNT SMD 058212
DS24 LED GRN REV MOUNT SMD 058212
DS25 LED GRN REV MOUNT SMD 058212
DS34 LED RGB SMD 058209
DS35 LED RGB SMD 058209
DS36 LED RGB SMD 058209
DS37 LED RGB SMD 058209
DS38 LED RGB SMD 058209
DS39 LED RGB SMD 058209
DS40 LED RGB SMD 058209
DS41 LED RGB SMD 058209
GP2 TERMINAL PC MOUNT 4-40 118115
GP3 TERMINAL PC MOUNT 4-40 118115
IR1 SENSOR IR 38KHZ 3V-5V 121066
J1 CONN 23 PIN FFC SMD 118004
J2 CONNECTOR 4 PIN HEADER 2MM 118014
J3 CONN 8 PIN FFC SMD 118118
J4 CONN 8 PIN FFC SMD 118118
J5 CONN 8 PIN FFC 117915
J6 CONN 8 PIN FFC 117915
J7 CONN 8 PIN FFC RA SMD 117933
J8 JACK HDPH 1/4” BLK W/ Switch 118117
J9 CONN 9 PIN FEMALE BOTTOM MOUNT 117987
J10 CONN 8 PIN FFC SMD 118118
J11 CONN 8 PIN FFC SMD 118118
J12 CONN 8 PIN FFC RA SMD 117933
J13 CONN 8 PIN FFC RA SMD 117933
J18 CONN 12 PIN FFC SMD 118001
J19 CONNECTOR LATCHING 2PIN RA SMD 118027
J20 CONNECTOR LATCHING 2PIN RA SMD 118027
J21 CONN 8 PIN FFC SMD 118118
L1 INDUCTOR 10UH 30% SMD 122438
MP1 SPACER LED 4MM LEN 163186
MP2 SPACER LED 4MM LEN 163186
MP3 SPACER LED 4MM LEN 163186
MP4 SPACER LED 4MM LEN 163186
PCB1 PC BD DISPLAY 130328
Q1 TRANSISTOR PNP A55 SMD 132334
Q2 TRANSISTOR PNP A55 SMD 132334
R1 RES TF 22.1 .5% .1W SMD0805 145113
R2 RES SMD0805 150 1/8W 1% 145019
R3 RES SMD0805 4.75K 1/8W 1% 145008
R4 RES TF 22.1 .5% .1W SMD0805 145113
R5 RES TF 22.1 .5% .1W SMD0805 145113
R6 RES TF 22.1 .5% .1W SMD0805 145113
R7 RES SMD0805 475K 1/8W 1% 145040
R8 RES SMD0805 150 1/8W 1% 145019
R9 RES SMD0805 221 1/8W 1% 145001
R10 RES SMD0805 4.75K 1/8W 1% 145008
R11 RES TF 1.20K 1% 0.1W SMD0805 145066
R12 RES SMD0805 3.32K 1/8W 1% 145026
R13 RES SMD0805 6.81K 1/8W 1% 145029
R14 RES SMD0805 18.2K 1/8W 1% 145031
R15 RES SMD0805 4.75K 1/8W 1% 145008
R16 RES SMD0805 6.81K 1/8W 1% 145029
R17 RES SMD0805 12.1K 1/8W 1% 145030
R18 RES SMD0805 2.74K 1/8W 1% 145025
R19 RES SMD0805 2.74K 1/8W 1% 145025
R20 RES SMD0805 2.74K 1/8W 1% 145025
R21 RES SMD0805 2.74K 1/8W 1% 145025
R22 RES SMD0805 12.1K 1/8W 1% 145030
R24 RES SMD0805 2.74K 1/8W 1% 145025
R26 RES SMD0805 12.1K 1/8W 1% 145030
R27 RES SMD0805 2.74K 1/8W 1% 145025
R28 RES SMD0805 2.74K 1/8W 1% 145025
R30 RES SMD0805 2.74K 1/8W 1% 145025
R31 RES SMD0805 2.74K 1/8W 1% 145025
R33 RES SMD0805 2.74K 1/8W 1% 145025
R34 RES SMD0805 2.74K 1/8W 1% 145025
R36 RES SMD0805 2.74K 1/8W 1% 145025
R37 RES SMD0805 2.74K 1/8W 1% 145025
R39 RES SMD0805 2.74K 1/8W 1% 145025
R41 RES SMD0805 12.1K 1/8W 1% 145030
R42 RES SMD0805 2.74K 1/8W 1% 145025
R44 RES SMD0805 2.74K 1/8W 1% 145025
R46 RES SMD0805 2.74K 1/8W 1% 145025
R47 RES SMD0805 2.74K 1/8W 1% 145025
R48 RES SMD0805 6.81K 1/8W 1% 145029
R49 RES SMD0805 2.74K 1/8W 1% 145025
R50 RES SMD0805 12.1K 1/8W 1% 145030
R51 RES SMD0805 6.81K 1/8W 1% 145029
R52 RES SMD0805 1.5K 1/8W 1% 145022
R53 RES SMD0805 3.92K 1/8W 1% 145027
R54 RES SMD0805 1.5K 1/8W 1% 145022
R55 RES SMD0805 3.92K 1/8W 1% 145027
R56 RES SMD0805 3.92K 1/8W 1% 145027
R57 RES SMD0805 1.5K 1/8W 1% 145022
R58 RES SMD0805 3.92K 1/8W 1% 145027
R59 RES SMD0805 1.5K 1/8W 1% 145022
R60 POT 1/4” HORIZ 1K OHM 1/2W SMD 134518
R61 POT 1/4” HORIZ 1K OHM 1/2W SMD 134518
R62 RES SMD0805 1.5K 1/8W 1% 145022
R63 RES SMD0805 3.92K 1/8W 1% 145027
R64 RES SMD0805 1.5K 1/8W 1% 145022
R65 RES SMD0805 3.92K 1/8W 1% 145027
R66 RES SMD0805 3.92K 1/8W 1% 145027
R67 RES SMD0805 1.5K 1/8W 1% 145022
R68 RES SMD0805 3.92K 1/8W 1% 145027
R69 RES SMD0805 1.5K 1/8W 1% 145022
R70 POT 1/4” HORIZ 1K OHM 1/2W SMD 134518
R71 POT 1/4” HORIZ 1K OHM 1/2W SMD 134518
S1 ENCODER OPTICAL ROTARY 146271
S2 ENCODER ROTARY W/ DETENT & PB 146272
S3 SWITCH TACT 260GF 5MM SMD 150072
S4 SWITCH TACT 260GF 5MM SMD 150072
S5 SWITCH TACT 260GF 5MM SMD 150072
S6 SWITCH TACT 260GF 5MM SMD 150072
S7 SWITCH TACT 260GF 5MM SMD 150072
U1 IC 8 BIT DRIVER SMD 133461

McIntosh C2600 Specifications

General

Signal to Noise Ratio	100dB
Phono Stage	Yes
Digital USB Input	1
Digital MCT Input	1
Vacuum Tube	Yes
Type	Tube Preamplifier
Frequency Response	20Hz - 20kHz (+0, -0.5dB)
Phono Inputs	1 Moving Magnet 1 Moving Coil
Outputs	3 Total
Output Impedance	100 ohms
Dimensions	17.5" (44.45cm) x 6" (15.24cm) x 18" (45.72cm)
Headphone Output	1/4" High Drive with Headphone Crossfeed Director (HXD®)
