74
Ref. No. Description Part No.
DSPLY/L PSHBTN/R PSHBTN/HDPHN/L MTR/R MTR PCB 751900
(Cont’d.)
Ref. No. Description Part No.
PARTS LIST (Cont’d.)
C1 CAP POLYPROP 0.22UF 400V 20% 064438
C2 CAP ELECT 22UF 35V SMD 066603
C3 CAP POLYPROP 0.22UF 400V 20% 064438
C4 CAP ELECT 22UF 35V SMD 066603
C5 CAP 22pF 200V 10% NPO SMD0805 061367
C6 CAP 22pF 200V 10% NPO SMD0805 061367
C7 CAP MPF 0.01UF 5% 250VDC 064472
C8 CAP 1000pF PPS 50V 2% SMD0805 061408
C9 CAP 1000pF PPS 50V 2% SMD0805 061408
C10 CAP 3300pF PPS 50V 2% SMD1206 064475
C11 CAP 3300pF PPS 50V 2% SMD1206 064475
C12 CAP 10pF 50V 2% SMD0805 061405
C13 CAP 10pF 50V 2% SMD0805 061405
C14 CAP ELECT 10UF 50V SMD 066602
C15 CAP ELECT 10UF 50V SMD 066602
C18 CAP 220pF 200V 10% NPO SMD0805 061369
C19 CAP 220pF 200V 10% NPO SMD0805 061369
C20 CAP ELECT 100UF 25V SMD 066605
C21 CAP ELECT 47UF 35V SMD 066604
C22 CAP ELECT 47UF 35V SMD 066604
C23 CAP MPF 0.01UF 5% 250VDC 064472
C24 CAP ELECT 10UF 250V 066558
C25 CAP 47pF 200V 10% NPO SMD0805 061368
C26 CAP 47pF 200V 10% NPO SMD0805 061368
C27 CAP ELECT 47UF 35V SMD 066604
C28 CAP ELECT 47UF 35V SMD 066604
C29 CAP MPF 0.01UF 5% 250VDC 064472
C30 CAP MPF 0.01UF 5% 250VDC 064472
C31 CAP 3300pF PPS 50V 2% SMD1206 064475
C32 CAP 220pF 200V 10% NPO SMD0805 061369
C33 CAP 10pF 50V 2% SMD0805 061405
C34 CAP 10pF 50V 2% SMD0805 061405
C35 CAP 3300pF PPS 50V 2% SMD1206 064475
C36 CAP 220pF 200V 10% NPO SMD0805 061369
C37 CAP ELECT 10UF 50V SMD 066602
C38 CAP ELECT 10UF 50V SMD 066602
C39 CAP 1000pF PPS 50V 2% SMD0805 061408
C40 CAP 1000pF PPS 50V 2% SMD0805 061408
C16 CAP POLYPROP 1uF 20% 250VDC 064433
C17 CAP POLYPROP 1uF 20% 250VDC 064433
C41 CAP POLYPROP 1uF 20% 250VDC 064433
C42 CAP POLYPROP 1uF 20% 250VDC 064433
DS1 LED RGB SMD 058209
DS2 LED RGB SMD 058209
DS3 LED RGB SMD 058209
DS4 LED RGB SMD 058209
DS5 LED RGB SMD 058209
DS6 LED RGB SMD 058209
J1 CONN 12 PIN FFC SMD 118001
J3 CONN 12 PIN FFC SMD 118001
J4 CONN 8 PIN 2.5MM SHROUDED 118046
J7 HEADER 2 PIN LATCHING 117766
J30 HEADER 2 PIN LATCHING 117766
J51 HEADER 2 PIN LATCHING 117766
J61 HEADER 2 PIN LATCHING 117766
PCB1 PC BD TUBE 130329
Q1 TRANSISTOR PNP 300V BF421 132352
Q2 TRANSISTOR PNP 300V BF421 132352
Q3 TRANSISTOR PNP 300V BF421 132352
Q4 TRANSISTOR PNP 300V BF421 132352
R1 RES SMD0805 475K 1/8W 1% 145040
R2 RES TF 49.9K 1% 0.1W SMD0805 145085
R3 RES TF 1K 1% 0.1W SMD0805 145117
R4 RES TF 221K .125W .5% SMD0805 145140
R5 RES SMD0805 4.75K 1/8W 1% 145008
R6 RES SMD0805 3.92K 1/8W 1% 145027
R7 RES TF 56.2K 1% 1/16W SMD0603 145059
R8 RES SMD0805 3.92K 1/8W 1% 145027
R9 RES SMD0805 15K 1/8W 1% 145011
R10 RES SMD0805 475K 1/8W 1% 145040
R11 RES SMD0805 4.75K 1/8W 1% 145008
R12 RES TF 49.9K 1% 0.1W SMD0805 145085
R13 RES TF 1K 1% 0.1W SMD0805 145117
R14 RES TF 221K .125W .5% SMD0805 145140
R15 RES SMD0805 4.75K 1/8W 1% 145008
R16 RES SMD0805 475K 1/8W 1% 145040
R17 RES TF 56.2K 1% 1/16W SMD0603 145059
R18 RES SMD0805 4.75K 1/8W 1% 145008
R19 RES SMD0805 27.4K 1/8W 1% 145032
R20 RES SMD0805 27.4K 1/8W 1% 145032
R21 RES TF 10K 1% 0.1W SMD0805 145061
R22 RES TF 100K 1% 0.1W SMD0805 145062
R23 RES TF 10K 1% 0.1W SMD0805 145061
R24 RES TF 100K 1% 0.1W SMD0805 145062
R25 RES TF 2.21K 1% 0.1W SMD0805 145126
R26 RES TF 2.21K 1% 0.1W SMD0805 145126
R27 RES SMD0805 15K 1/8W 1% 145011
R28 RES TF 2.21K 1% 0.1W SMD0805 145126
R29 RES TF 2.21K 1% 0.1W SMD0805 145126
R30 RES TF 2.21K 1% 0.1W SMD0805 145126
R31 RES TF 681K 1% 0.125W SMD0805 145129
R32 RES TF 681K 1% 0.125W SMD0805 145129
R33 RES SMD0805 2.21M 1/8W 1% 145043
R34 RES SMD0805 2.21M 1/8W 1% 145043
R35 RES TF 1M 1% 0.125W SMD0805 145131
R36 RES TF 1M 1% 0.125W SMD0805 145131
R37 RES SMD0805 4.75K 1/8W 1% 145008
R38 RES SMD0805 475K 1/8W 1% 145040
R39 RES TF 75K 1% 0.125W SMD0805 145130
R40 RES TF 75K 1% 0.125W SMD0805 145130
R41 RES SMD0805 27.4K 1/8W 1% 145032
R42 RES SMD0805 27.4K 1/8W 1% 145032
R43 RES SMD0805 27.4K 1/8W 1% 145032
R44 RES SMD0805 27.4K 1/8W 1% 145032
R45 RES MF 47.5K 1% 1/4W 144526
R46 RES MF 47.5K 1% 1/4W 144526
R47 RES TF 953 1% 0.1W SMD0805 145127
R48 RES SMD0805 4.75K 1/8W 1% 145008
R49 RES TF 953 1% 0.1W SMD0805 145127
R50 RES SMD0805 4.75K 1/8W 1% 145008
R51 RES TF 681K 1% 0.125W SMD0805 145129
R52 RES TF 681K 1% 0.125W SMD0805 145129
R53 RES SMD0805 2.21M 1/8W 1% 145043
TUBE PCB 751901
11
U2 IC SINGLE NAND SCHMITT SMD 133724
U3 IC DUAL OP-AMP RAIL SMD 133714
U4 IC SINGLE NAND SCHMITT SMD 133724
5
6
7
8
9
10
