McIntosh C2600 Service Manual

C2600
75
Ref. No. Description Part No.
TUBE PCB 751901 (Cont’d.)
Ref. No. Description Part No.
PARTS LIST (Cont’d.)
R54 RES SMD0805 2.21M 1/8W 1% 145043
R55 RES TF 100K 1% 0.1W SMD0805 145062
R56 RES TF 100K 1% 0.1W SMD0805 145062
R57 RES TF 1M 1% 0.125W SMD0805 145131
R58 RES TF 1M 1% 0.125W SMD0805 145131
R59 RES SMD0805 4.75K 1/8W 1% 145008
R60 RES SMD0805 4.75K 1/8W 1% 145008
R61 RES SMD0805 475K 1/8W 1% 145040
R62 RES SMD0805 475K 1/8W 1% 145040
R63 RES TF 75K 1% 0.125W SMD0805 145130
R64 RES TF 75K 1% 0.125W SMD0805 145130
R65 RES SMD0805 27.4K 1/8W 1% 145032
R66 RES SMD0805 27.4K 1/8W 1% 145032
R67 RES SMD0805 27.4K 1/8W 1% 145032
R68 RES TF 10K 1% 0.1W SMD0805 145061
R69 RES SMD0805 27.4K 1/8W 1% 145032
R70 RES SMD0805 27.4K 1/8W 1% 145032
R71 RES SMD0805 27.4K 1/8W 1% 145032
R72 RES TF 10K 1% 0.1W SMD0805 145061
R73 RES TF 2.21K 1% 0.1W SMD0805 145126
R74 RES TF 2.21K 1% 0.1W SMD0805 145126
R75 RES SMD0805 4.75K 1/8W 1% 145008
V1 SOCKET TUBE 9 PIN GOLD 178195
V2 SOCKET TUBE 9 PIN GOLD 178195
V3 SOCKET TUBE 9 PIN GOLD 178195
V4 SOCKET TUBE 9 PIN GOLD 178195
V5 SOCKET TUBE 9 PIN GOLD 178195
V6 SOCKET TUBE 9 PIN GOLD 178195
C1 CAP ELECT 22UF 100V 066574
C2 CAP ELECT 22UF 100V 066574
C3 CAP ELECT 22UF 100V 066574
C4 CAP ELECT 22UF 100V 066574
C5 CAP ELECT 22UF 100V 066574
C6 CAP ELECT 22UF 100V 066574
C7 CAP ELECT 22UF 100V 066574
C8 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C9 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C10 CAP ELECT 22UF 100V 066574
C11 CAP ELECT 22UF 100V 066574
C12 CAP ELECT 22UF 100V 066574
C13 CAP ELECT 22UF 100V 066574
C14 CAP ELECT 22UF 100V 066574
C15 CAP ELECT 22UF 100V 066574
C16 CAP ELECT 22UF 100V 066574
C17 CAP ELECT 22UF 100V 066574
C18 CAP ELECT 22UF 100V 066574
C19 CAP ELECT 22UF 100V 066574
C20 CAP ELECT 22UF 100V 066574
C21 CAP ELECT 22UF 100V 066574
C22 CAP ELECT 22UF 100V 066574
C23 CAP ELECT 22UF 100V 066574
C24 CAP ELECT 22UF 100V 066574
C25 CAP ELECT 22UF 100V 066574
D1 DIODE SMALL SIGNAL 4148 SMD 070199
D2 DIODE SMALL SIGNAL 4148 SMD 070199
D3 DIODE SMALL SIGNAL 4148 SMD 070199
D4 DIODE ESD SUPPRESSOR SMD 070198
OUTPUT PCB 751747
12
11
D5 DIODE ESD SUPPRESSOR SMD 070198
D6 DIODE ESD SUPPRESSOR SMD 070198
D7 DIODE ESD SUPPRESSOR SMD 070198
D8 DIODE ESD SUPPRESSOR SMD 070198
D9 DIODE ESD SUPPRESSOR SMD 070198
D10 DIODE ESD SUPPRESSOR SMD 070198
D11 DIODE ESD SUPPRESSOR SMD 070198
D12 DIODE ESD SUPPRESSOR SMD 070198
D13 DIODE ESD SUPPRESSOR SMD 070198
D14 DIODE ESD SUPPRESSOR SMD 070198
D15 DIODE ESD SUPPRESSOR SMD 070198
D16 DIODE ESD SUPPRESSOR SMD 070198
D17 DIODE ESD SUPPRESSOR SMD 070198
D18 DIODE ESD SUPPRESSOR SMD 070198
D19 DIODE ESD SUPPRESSOR SMD 070198
D20 DIODE ESD SUPPRESSOR SMD 070198
D21 DIODE ESD SUPPRESSOR SMD 070198
J1 CONN 18 PIN FFC RA SMD 117997
J2 JACK DUAL RCA 118020
J3 RECEPTACLE XLR MALE 117686
J4 RECEPTACLE XLR MALE 117686
J5 RECEPTACLE XLR MALE 117686
J6 RECEPTACLE XLR MALE 117686
J7 RECEPTACLE XLR MALE 117686
J8 RECEPTACLE XLR MALE 117686
J9 JACK DUAL RCA 118020
J10 JACK DUAL RCA 118020
K1 RELAY REED FORM 1C 5V 125 OHM 087056
K2 RELAY REED FORM 1C 5V 125 OHM 087056
K3 RELAY REED FORM 1C 5V 125 OHM 087056
K4 RELAY REED FORM 1C 5V 125 OHM 087056
K5 RELAY REED FORM 1C 5V 125 OHM 087056
K6 RELAY REED FORM 1C 5V 125 OHM 087056
K7 RELAY REED FORM 1C 5V 125 OHM 087056
K8 RELAY REED FORM 1C 5V 125 OHM 087056
K9 RELAY REED FORM 1C 5V 125 OHM 087056
K10 RELAY REED FORM 1C 5V 125 OHM 087056
K11 RELAY REED FORM 1C 5V 125 OHM 087056
K12 RELAY REED FORM 1C 5V 125 OHM 087056
PCB1 PC BD OUTPUT 130272
R1 RES TF 100 1% 0.1W SMD0805 145060
R2 RES TF 100 1% 0.1W SMD0805 145060
R3 RES TF 100 1% 0.1W SMD0805 145060
R4 RES TF 100 1% 0.1W SMD0805 145060
R5 RES TF 100 1% 0.1W SMD0805 145060
R6 RES TF 100 1% 0.1W SMD0805 145060
R7 RES FP 1.1 OHM 1/4W 5% 137002
R8 RES FP 1.1 OHM 1/4W 5% 137002
R9 RES TF 100K 1% 0.1W SMD0805 145062
R10 RES TF 100K 1% 0.1W SMD0805 145062
R11 RES TF 100K 1% 0.1W SMD0805 145062
R12 RES TF 100K 1% 0.1W SMD0805 145062
R13 RES TF 100K 1% 0.1W SMD0805 145062
R14 RES TF 100K 1% 0.1W SMD0805 145062
R15 RES SMD0805 22.1K 1/8W 1% 145012
R16 RES SMD0805 22.1K 1/8W 1% 145012
R17 RES SMD0805 22.1K 1/8W 1% 145012
R18 RES SMD0805 22.1K 1/8W 1% 145012
R19 RES TF 10K 1% 0.1W SMD0805 145061

McIntosh C2600 Specifications

General

Signal to Noise Ratio	100dB
Phono Stage	Yes
Digital USB Input	1
Digital MCT Input	1
Vacuum Tube	Yes
Type	Tube Preamplifier
Frequency Response	20Hz - 20kHz (+0, -0.5dB)
Phono Inputs	1 Moving Magnet 1 Moving Coil
Outputs	3 Total
Output Impedance	100 ohms
Dimensions	17.5" (44.45cm) x 6" (15.24cm) x 18" (45.72cm)
Headphone Output	1/4" High Drive with Headphone Crossfeed Director (HXD®)
