76
Ref. No. Description Part No.
OUTPUT PCB 751747 (Cont’d.)
Ref. No. Description Part No.
PARTS LIST (Cont’d.)
12
R20 RES TF 10K 1% 0.1W SMD0805 145061
R21 RES TF 10K 1% 0.1W SMD0805 145061
R22 RES TF 10K 1% 0.1W SMD0805 145061
R23 RES SMD0805 22.1K 1/8W 1% 145012
R24 RES SMD0805 22.1K 1/8W 1% 145012
R25 RES SMD0805 22.1K 1/8W 1% 145012
R26 RES SMD0805 22.1K 1/8W 1% 145012
R27 RES SMD0805 22.1K 1/8W 1% 145012
R28 RES SMD0805 22.1K 1/8W 1% 145012
R29 RES SMD0805 22.1K 1/8W 1% 145012
R30 RES SMD0805 22.1K 1/8W 1% 145012
R31 RES SMD0805 22.1K 1/8W 1% 145012
R32 RES SMD0805 22.1K 1/8W 1% 145012
R33 RES SMD0805 22.1K 1/8W 1% 145012
R34 RES SMD0805 22.1K 1/8W 1% 145012
R35 RES TF 100K 1% 0.1W SMD0805 145062
R36 RES TF 100K 1% 0.1W SMD0805 145062
R37 RES TF 100K 1% 0.1W SMD0805 145062
R38 RES TF 100K 1% 0.1W SMD0805 145062
R39 RES TF 100K 1% 0.1W SMD0805 145062
R40 RES TF 100K 1% 0.1W SMD0805 145062
R41 RES TF 100K 1% 0.1W SMD0805 145062
R42 RES TF 100K 1% 0.1W SMD0805 145062
R43 RES TF 100K 1% 0.1W SMD0805 145062
R44 RES TF 100K 1% 0.1W SMD0805 145062
R45 RES TF 100K 1% 0.1W SMD0805 145062
R46 RES TF 100K 1% 0.1W SMD0805 145062
R47 RES TF 100 1% 0.1W SMD0805 145060
R48 RES TF 100 1% 0.1W SMD0805 145060
R49 RES TF 100 1% 0.1W SMD0805 145060
R50 RES TF 100 1% 0.1W SMD0805 145060
R51 RES TF 100 1% 0.1W SMD0805 145060
R52 RES TF 100 1% 0.1W SMD0805 145060
R53 RES TF 100 1% 0.1W SMD0805 145060
R54 RES TF 100 1% 0.1W SMD0805 145060
R55 RES TF 100 1% 0.1W SMD0805 145060
R56 RES TF 100 1% 0.1W SMD0805 145060
R57 RES TF 100 1% 0.1W SMD0805 145060
R58 RES TF 100 1% 0.1W SMD0805 145060
U1 IC DUAL OP AMP 5532 SMD 133718
U2 IC DUAL OP AMP 5532 SMD 133718
