MC2000 Front Panel Controls and Displays
POWER Switch turns AC Power,
ON/OFF, or ON/REMOTE modes
METER indicates the Left Channel Power Output,
switchable to indicate bias readings of each pair of
Left Channel Output Tubes
METER indicates the Right Channel Power Output,
switchable to indicate bias readings of each pair of
Right Channel Output Tubes
Remote On Indicator
METER Switch selects the display
modes of the power output meters
