McIntosh MC207 Service Manual

Ref
No. Description
Part
No.
PARTS LIST
050065 INPUT PCB
C1 CAP ELECT 10UF 16V 4X5 CASE
066382
C2 CAP ELECT 10UF 16V 4X5 CASE
066382
C3 CAP MONO 47PF 200V 10% NPO
061299
C4 CAP MONO 47PF 200V 10% NPO
061299
C5 CAP ELECT 10UF 16V 4X5 CASE
066382
C6 CAP ELECT 10UF 16V 4X5 CASE
066382
C7 CAP MONO .1uF 50V 20% Z5U
061305
C8 CAP MONO .1uF 50V 20% Z5U
061305
C9 CAP MONO 22PF 200V 10% NPO
061298
C10 CAP MONO 22PF 200V 10% NPO
061298
C11 CAP MONO 47PF 200V 10% NPO
061299
C12 CAP ELECT 10UF 50V 066445
C13 CAP MONO 47PF 200V 10% NPO
061299
C14 CAP ELECT 10UF 50V 066445
C15 CAP ELECT 10UF 16V 4X5 CASE
066382
C16 CAP ELECT 10UF 16V 4X5 CASE
066382
C17 CAP MONO 47PF 200V 10% NPO
061299
C18 CAP ELECT 10UF 16V 4X5 CASE
066382
C19 CAP MONO 47PF 200V 10% NPO
061299
C20 CAP MONO .1uF 50V 20% Z5U
061305
C21 CAP MONO .1uF 50V 20% Z5U
061305
C22 CAP ELECT 10UF 16V 4X5 CASE
066382
C23 CAP MONO 22PF 200V 10% NPO
061298
C24 CAP MONO .1uF 50V 20% Z5U
061305
C25 CAP MONO .1uF 50V 20% Z5U
061305
C26 CAP MONO 47PF 200V 10% NPO
061299
C27 CAP MONO 22PF 200V 10% NPO
061298
C28 CAP MONO 47PF 200V 10% NPO
061299
C29 CAP ELECT 10UF 16V 4X5 CASE
066382
C30 CAP MONO 47PF 200V 10% NPO
061299
C31 CAP ELECT 10UF 16V 4X5 CASE
066382
C32 CAP MONO 22PF 200V 10% NPO
061298
C33 CAP MONO 47PF 200V 10% NPO
061299
C34 CAP ELECT 10UF 16V 4X5 CASE
066382
C35 CAP MONO 47PF 200V 10% NPO
061299
C36 CAP ELECT 10UF 16V 4X5 CASE
066382
C38 CAP MONO 22PF 200V 10% NPO
061298
C39 CAP MONO .1uF 50V 20% Z5U
061305
C40 CAP MONO .1uF 50V 20% Z5U
061305
C41 CAP MONO 47PF 200V 10% NPO
061299
C43 CAP ELECT 10UF 16V 4X5 CASE
066382
C44 CAP MONO 47PF 200V 10% NPO
061299
C45 CAP ELECT 10UF 16V 4X5 CASE
066382
C46 CAP MONO 22PF 200V 10% NPO
061298
C47 CAP MONO 22PF 200V 10% NPO
061298
J1 CONN MALE 9 POS FRICTION LOCK
117244
J2 JACK RCA BLK 117847
J3 JACK RCA 1X2 BLK/BLK 14MM
117848
J4 CONN 4 PIN 117215
J5 CONN 4 PIN 117215
J6 RECEPTACLE XLR FEMALE 117685
J7 RECEPTACLE XLR FEMALE 117685
J8 JACK RCA 1X2 BLK/BLK 14MM
117848
J9 CONN 4 PIN 117215
J10 CONN D 25-PIN 117501
J11 CONN 4 PIN 11721
J12 RECEPTACLE XLR FEMALE 117685
J13 RECEPTACLE XLR FEMALE 117685
36
2
1

McIntosh MC207 Specifications

General

Damping factor	140
Amplifier class	-
Frequency range	10 - 100000 Hz
RMS rated power	1400 W
Output impedance	8 Ω
Audio output channels	7.1 channels
Peak power per channel	200 W
Signal-to-Noise Ratio (SNR)	112 dB
Total Harmonic Distortion (THD)	0.000 %
XLR in	Yes
Speakers connectivity type	Binding post
Purpose	Home
Product color	Black
Volume control	Rotary
Connectivity technology	Wired
Maximum current	12 A
AC input voltage	120 V
AC input frequency	50 - 60 Hz

Weight and Dimensions

Depth	533 mm
Width	445 mm
Height	239 mm
Weight	37600 g
