McIntosh MC207 Service Manual

R105 RES MF 6.49K 1% 1/4W 144140
R106 RES MF 475 OHM 1% 1/4W 144086
R107 RES MF 475 OHM 1% 1/4W 144086
R108 RES MF 6.49K 1% 1/4W 144140
R109 RES CF 0 ohm 141389
R110 RES MET OX 430 OHM 5% .5W
137095
R111 RES MET OX 430 OHM 5% .5W
137095
R112 RES MF 1M 1/4W 144269
R113 RES CF 10 OHM 5% 1/2W 141165
R114 RES CF 10 OHM 5% 1/2W 141165
R115 RES MF 1M 1/4W 144269
R119 RES MO 4.7 OHM 1W 5% 144464
R120 RES MO 4.7 OHM 1W 5% 144464
R122 RES MF 47.5K 1% 1/4W 144108
R123 RES MF 22.1K 1% 1/4W 144187
R124 RES MF 47.5K 1% 1/4W 144108
RT1 THERMAL 144249
RT2 THERMAL 144249
050066 DISPLAY PCB
C1 CAP ELECT 10UF 50V 066445
C2 CAP MPF 0.47UF 5% 50/63VDC
064333
C3 CAP MONO .1uF 50V 20% Z5U
061305
C4 CAP MONO .1uF 50V 20% Z5U
061305
C5 CAP MPF 0.1UF 5% 63VDC 064325
C6 CAP ELECT 10UF 50V 066445
C7 CAP MPF 0.47UF 5% 50/63VDC
064333
C8 CAP MONO .1uF 50V 20% Z5U
061305
C9 CAP MONO .1uF 50V 20% Z5U
061305
C10 CAP MPF 0.1UF 5% 63VDC 064325
C11 CAP ELECT 10UF 50V 066445
C12 CAP MPF 0.47UF 5% 50/63VDC
064333
C13 CAP MONO .1uF 50V 20% Z5U
061305
C14 CAP ELECT 100UF 16V OR 25V
066447
C15 CAP MPF 0.1UF 5% 63VDC 064325
C16 CAP MONO .1uF 50V 20% Z5U
061305
D1 DIODE SILICON 070047
D2 DIODE SILICON 070047
D3 DIODE SILICON 070047
D4 DIODE SILICON 070047
D5 DIODE SILICON 070047
D6 DIODE SILICON 070047
D7 DIODE SILICON 070047
D8 DIODE SILICON 070047
D9 DIODE SILICON 070047
D10 DIODE SILICON 070047
D11 DIODE SILICON 070047
D12 DIODE SILICON 070047
D13 DIODE SILICON 070047
D14 DIODE SILICON 070047
D15 DIODE SILICON 070047
D16 DIODE SILICON 070047
D17 DIODE SILICON 070047
D18 DIODE SILICON 070047
D19 DIODE SILICON 070047
D20 DIODE SILICON 070047
D21 DIODE SILICON 070047
D22 DIODE SILICON 070047
D23 DIODE SILICON 070047
D24 DIODE SILICON 070047
D25 DIODE SILICON 070047
D26 DIODE SILICON 070047
D27 DIODE SILICON 070047
D28 DIODE SILICON 070047
D29 DIODE SILICON 070047
D30 DIODE SILICON 070047
DS1 LED BLUE 5MM HI-INTENSITY
“VF[V] 3.6””” 058166(1)112108(1)
DS2 LED BLUE 5MM HI-INTENSITY
“VF[V] 3.6””” 058166(1)112108(1)
DS3 LED GREEN 5MM HI-INTENSITY
“VF[V] 3.5””” 058165(1)112108(1)
DS4 LED GREEN 5MM HI-INTENSITY
“VF[V] 3.5””” 058165(1)112108(1)
DS5 LED RED HIGH EFFICIENCY 058148
DS6 LED BLUE 5MM HI-INTENSITY
“VF[V] 3.6””” 058166(1)112108(1)
DS7 LED BLUE 5MM HI-INTENSITY
“VF[V] 3.6””” 058166(1)112108(1)
DS8 LED GREEN 5MM HI-INTENSITY
“VF[V] 3.5””” 058165(1)112108(1)
DS9 LED GREEN 5MM HI-INTENSITY
PARTS LIST con’t
42
6
7

McIntosh MC207 Specifications

General

Damping factor	140
Amplifier class	-
Frequency range	10 - 100000 Hz
RMS rated power	1400 W
Output impedance	8 Ω
Audio output channels	7.1 channels
Peak power per channel	200 W
Signal-to-Noise Ratio (SNR)	112 dB
Total Harmonic Distortion (THD)	0.000 %
XLR in	Yes
Speakers connectivity type	Binding post
Purpose	Home
Product color	Black
Volume control	Rotary
Connectivity technology	Wired
Maximum current	12 A
AC input voltage	120 V
AC input frequency	50 - 60 Hz

Weight and Dimensions

Depth	533 mm
Width	445 mm
Height	239 mm
Weight	37600 g
