McIntosh MHA100

6
Dimensions
Dimensions
The following dimensions can assist in determining
the best location for your MHA100. There is addition-
al information on the next page pertaining to install-
ing the MHA100 into cabinets.
Rear View of the MHA100
Side View of the MHA100
Front View of the MHA100
9/16"
1.4cm
29/32
"
1.8cm
10-13/16"
27.5cm
8"
20.3cm
11-1/2"
29.2cm
5-3/8"
13.7cm
5-9/16"
14.1cm
14-5/8"
37.1cm
9-1/2"
24.1cm
4-11/16"
4.3cm
12-5/8"
32.1cm
1-1/2"
3.8cm
1-11/16"
4.3cm
