McIntyre 407 - Changing the Suction Filter

43
320/407/500/600.41912-ENG
6.10. Changing the Suction Filter
(See Illustration 7.2, Page 48).
Always switch off and isolate the Shear from the mains
electrical supply before maintenance.
• Isolate the Shear from the Mains Power Supply. Disconnect the Motor Cable at the
Motor Terminal Box.
• Unscrew the four Fasteners, Items 2.35, then using suitable lifting equipment lift up
the Electric Motor and store away from the working area.
• Unscrew the four Bell Housing Studs, Items 2.3, then lift the Bellhousing to reveal
the Hydraulic Pump, Item 2.21.
Do Not try to lift the Pump clear of the Tank.
• Unscrew the Hydraulic Pump Hose, Item 2.11, connection taking care not to
damage the gasket.
• Lift the Bell Housing further to expose the Suction Filter, Item 2.24. Unscrew the
lterfromthePumpttingandreplacewithanewitem.
• Reassemble in reverse.
