- 8 -
Light On/Off set
: Press
Key.
Sound set
: Press
Key.
: Sound on.
: Transmitter sound off. Function sound on.
: Sound off.
Press and hold
for 2 seconds.
Note : The last setting is memorized after the unit is Turned OFF
3) 12-pin connector
The Direct connection cord or the External coil cord are plugged into the 12-pin connector.
4) Battery compartment
Replace all batteries when there is a low battery condition.
Use ten 1.5V alkaline type D (LR20 / 13A) batteries.
Transmitter sound:
ALWAYS CHECK THE BATTERY POLARITY BEFORE
CLOSING THE COMPARTMENT
Beep…(15sec.)…..Beep…(15sec)…Beep
Light On
Light Off
Mode
Battery 0％
Battery 100％
Unfasten the two hooks.
12-pin connector
DC input
