McLaughlin Vision GX2 - Null Mode; Peak Mode

- 23 -
8-2. Null mode
Start
ing
Null Mode
To find
the direction of the object line,
using
the Yaw Angle Display
8-3. Peak mode
Start
ing
Peak Mode
Method of this
Mode
Peak mode is almost same as Peak & Null mode.
The difference is that there are no Null functions. See the
Peak & Null Mode Page 22.
*Real time depth and current are displayed when “D /CU”
setting is on. See page 10.
150
40
30
550
PE!
Move in the direction of
the arrow.
100
Buried cable
OUT OF RANGE
Number of receiving level
is blinked.
340
300
TOP of the object line
The arrows are indicated on the both side.
Beep sound is emitted.
Real time depth or current index is
displayed on the bottom line.
The direction of the
object line.
Null mode
Receiving level
Digital level
Gain setting value
Yaw angle
Real time depth
Direction of the buried cable.
Yaw angle
Select null
Press PEAK / NULL key.
To find the position of the object line
Bar-graph
(Sensibility and L/R direction)
Select peak
Press PEAK / NULL key.
Operational frequency or
Real time Current index
Distance is approximately
same as depth
Distance is approximately
same as depth
