Table 8, Spring Vibration Isolators, Copper Fin, AGS-CS/H
Mounting Location
AGS
Model
M1 M2 M3 M4 M5 M6 Kit Number
CP2-31 CP2-31 CP2-31 CP2-31 CP2-28 CP2-28
120
GRAY GRAY GRAY GRAY GREEN GREEN
330904102
CP2-32 CP2-32 CP2-31 CP2-31 CP2-31 CP2-31
125
WHITE WHITE GRAY GRAY GRAY GRAY
330904105
CP2-31 CP2-31 CP2-31 CP2-31 CP2-28 CP2-28
130
GRAY GRAY GRAY GRAY GREEN GREEN
330904102
CP2-32 CP2-32 CP2-31 CP2-31 CP2-31 CP2-31
135
WHITE WHITE GRAY GRAY GRAY GRAY
330904105
CP2-31 CP2-31 CP2-31 CP2-31 CP2-28 CP2-28
140
GRAY GRAY GRAY GRAY GREEN GREEN
330904102
CP2-31 CP2-31 CP2-31 CP2-31 CP2-31 CP2-31
145
GRAY GRAY GRAY GRAY GRAY GRAY
330904104
CP2-31 CP2-31 CP2-31 CP2-31 CP2-31 CP2-31
160
GRAY GRAY GRAY GRAY GRAY GRAY
330904104
CP2-32 CP2-32 CP2-32 CP2-32 CP2-31 CP2-31
165
WHITE WHITE WHITE WHITE GRAY GRAY
330904106
CP2-32 CP2-32 CP2-31 CP2-31 CP2-31 CP2-31
170
WHITE WHITE GRAY GRAY GRAY GRAY
330904105
CP2-32 CP2-32 CP2-32 CP2-32 CP2-31 CP2-31
175
WHITE WHITE WHITE WHITE GRAY GRAY
330904106
CP2-32 CP2-32 CP2-31 CP2-31 CP2-31 CP2-31
180
WHITE WHITE GRAY GRAY GRAY GRAY
330904105
CP2-32 CP2-32 CP2-31 CP2-31 CP2-31 CP2-31
190
WHITE WHITE GRAY GRAY GRAY GRAY
330904105
CP2-32 CP2-32 CP2-32 CP2-32 CP2-31 CP2-31
195
WHITE WHITE WHITE WHITE GRAY GRAY
330904106
CP2-32 CP2-32 CP2-32 CP2-32 CP2-31 CP2-31
210
WHITE WHITE WHITE WHITE GRAY GRAY
330904106
Table 9, Neoprene-in-Shear Isolators, Copper Fin, AGS-CS/H
Mounting Location (See Footprint Drawing, pg. 13)
AGS
Model
M1 M2 M3 M4 M5 M6 Kit Number
120
RP-4, RED RP-4, RED RP-4, RED RP-4, RED RP-4, RED RP-4, RED
125
RP-4, RED RP-4, RED RP-4, RED RP-4, RED RP-4, RED RP-4, RED
130
RP-4, RED RP-4, RED RP-4, RED RP-4, RED RP-4, RED RP-4, RED
135
RP-4, RED RP-4, RED RP-4, RED RP-4, RED RP-4, RED RP-4, RED
140
RP-4, RED RP-4, RED RP-4, RED RP-4, RED RP-4, RED RP-4, RED
145
RP-4, RED RP-4, RED RP-4, RED RP-4, RED RP-4, RED RP-4, RED
160
RP-4, RED RP-4, RED RP-4, RED RP-4, RED RP-4, RED RP-4, RED
330904112
165
RP-4, GRN RP-4, GRN RP-4, GRN RP-4, GRN RP-4, RED RP-4, RED 330904113
170
RP-4, RED RP-4, RED RP-4, RED RP-4, RED RP-4, RED RP-4, RED 330904112
175
RP-4, GRN RP-4, GRN RP-4, GRN RP-4, GRN RP-4, RED RP-4, RED 330904113
180
RP-4, RED RP-4, RED RP-4, RED RP-4, RED RP-4, RED RP-4, RED
190
RP-4, RED RP-4, RED RP-4, RED RP-4, RED RP-4, RED RP-4, RED
330904112
195
RP-4, GRN RP-4, GRN RP-4, GRN RP-4, GRN RP-4, RED RP-4, RED
210
RP-4, GRN RP-4, GRN RP-4, GRN RP-4, GRN RP-4, RED RP-4, RED
330904113
